Airtac 3V-F Base 3V300M9F
The AirTAC Airtac 3V-F Base 3V300M9F is a genuine 3V-F manifold base manifold base for 9 stations on one shared air supply. A base is a machined block: it carries no coil and no solenoid, so the valves that sit on it are ordered separately.
- Valve type3/2-way (3-port, 2-position)
- Stations9
- Series3V-F manifold base
About the Airtac 3V-F Base 3V300M9F
Nine functions, one block. The 3V300M9F is a machined manifold base that carries nine 3/2 solenoid valves on a single shared air supply, so a large bank of switching points - clamps, blow-offs, pilot signals to bigger valves - hangs off one feed instead of nine tees.
There is no coil, voltage or electrical state in the base itself; those are properties of the valves ordered separately. It is a genuine AirTAC part, and we are glad to confirm the datasheet figures for base and valves whenever you ask.
Airtac 3V-F Base 3V300M9F Technical Specifications
| Model | Airtac 3V-F Base 3V300M9F |
|---|---|
| Series | 3V-F manifold base |
| Item form | Manifold base (no coil, no solenoid, no initial state) |
| Stations | 9 |
| Port size | Confirm from the datasheet — ask us |
| Thread | PT |
| Operating pressure | Confirm from the datasheet — ask us |
|---|---|
| Flow coefficient | Confirm from the datasheet — ask us |
| Temperature | Confirm from the datasheet — ask us |
| Protection | Confirm from the datasheet — ask us |
Model Code: Airtac 3V-F Base 3V300M9F
| 3V-F manifold base | Body. |
|---|---|
| 9F | 9 stations in one assembly. |
| PT | Port thread. PT ships from stock; G and NPT are available to order. |
What a 3/2 Valve Does
A 3/2 valve has three ports — supply, outlet and exhaust — and two states. It either feeds the outlet or vents it to exhaust, and that is the whole job.
That makes it the right valve for a single-acting (spring-return) cylinder, on/off air blow, a clamp, switching a vacuum generator or suction cup, and piloting a larger valve.
It cannot run a double-acting cylinder. A double-acting cylinder needs air alternately on two sides, which takes a 5-port valve — the AirTAC 4V series.
Where the Airtac 3V-F Base 3V300M9F Is Used
Robotic welding cell clamps
Switch each fixture clamp around a robotic welding cell from one manifold mounted in the cell cabinet.
Test rig switching bank
Route compressed air to different circuits of a leak or pressure test rig station by station from one block.
Service workshop blow-off set
Give a heavy-vehicle service workshop several blow-off and clamp points fed from one manifold on the wall.
Is the Airtac 3V-F Base 3V300M9F the Right Part?
The buying path is simple: the base first, then one 3/2 valve per station. For each valve decide NC or NO, the port step from M5 up to 3/8 inch, the coil voltage that matches your panel, and DIN plug or flying-lead entry. Thread is PT as standard across this family, with G and NPT available as catalogue options to order. Send us the actuator list and we will confirm sizing from the datasheet before you commit - and if published flow figures matter today, the AirTAC 3V2 and 3V3 bodies carry them. Double-acting actuation calls for the 5-port AirTAC 4V series instead.
Confirm before you order
- ✓ Port size and thread (PT from stock; G / NPT to order)
- ✓ Initial state — NC or NO, ordered up front
- ✓ Coil voltage matches your controller output
- ✓ Electrical entry — DIN plug or flying lead
- ✓ Single valve, bare base, or complete assembly
- ✓ Single-acting duty, not double-acting
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Use the manual override to test before powering up.
- check Leave the exhaust port clear, or fit a silencer.
- check Blank any unused station on the base before pressurising.
- check Wiring by qualified personnel, per AirTAC documentation.
Airtac 3V-F Base 3V300M9F FAQ
Not on this page - this listing is configuration only, and we confirm pressure, flow and coil power from the datasheet on request. If you need figures published up front, the AirTAC 3V2 and 3V3 valve bodies are the documented members of the range.
No. A 3/2 valve feeds or vents a single outlet, which suits single-acting cylinders, blow-off and piloting larger valves. A double-acting cylinder needs two outlet ports, so use an AirTAC 4V series 5-port valve for that.
