Airtac 4V100 Solenoid Valve 4V11006B-AM
1. Pilot operation: Selectable internal pilot or external pilot configuration;
2. Spool-type structure ensures excellent sealing performance and rapid response;
3. Three-position variants offer three distinct center-position functions;
4. Double solenoid 5/2-way configuration features latching (memory) function;
5. Special bore machining process minimizes friction resistance, achieves low actuation pressure (0.15MPa), and extends service life;
6. Lubrication-free operation;
7. Integrable with manifold bases for space-optimized valve arrangements;
8. Manual override provided for simplified installation and commissioning;
9. Multiple standard voltage options available (AC/DC).
Category: Solenoid Valves | Brand: AIRTAC | Series: 4V100
AirTAC 4V100 Solenoid Valve 4V11006B-AM Technical Specifications
- Model: 4V11006B-AM (4V100 series)
- Type: 5/2-way monostable (direct-acting)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow rate: 750 l/min (Cv=1.3 at 0.5 MPa)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 450g ±5% (including coil)
- Dimensions: 58mm(L) × 46mm(W) × 78mm(H) (body only, exclude fittings)
- Seal material: Heat-resistant NBR (Nitrile) - compatible with ISO 5599/1
- Ambient temperature: -5℃ to 60℃ (with no condensation)
- Fluid temperature: 0℃ to 60℃
- Power consumption: 2.8W (DC), 5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (internal threaded connection)
High-flow 5-port pneumatic valve with manual override, featuring corrosion-resistant anodized aluminum body and reinforced coil housing. Designed for rapid cycling applications requiring precise directional control, with integrated LED position indicator (on select voltage models). Compatible with ISO 15407-1 standards for industrial automation systems.
- Multi-axis pneumatic cylinder control in packaging machinery
- Pneumatic clamping systems for CNC fixtures
- Air logic circuits in food processing equipment
- Actuator control in semiconductor wafer handling systems
- Vacuum generator switching in automated material handling
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use 5μm filtration (40μm for exhaust). Lubricate with ISO VG32 turbine oil
if air line lubrication is used. Perform quarterly seal inspections in
high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | 4V11006B-AM |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
