AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM)
The AirTAC AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) is a genuine 5/2-way single solenoid (spring return) solenoid valve with AM ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port sizeAM
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM)
The AirTAC 4V41015C-AM is a 5/2-way single-solenoid directional control valve on the largest 4V body, with a 1/2 inch PT port and an AC110V coil wired through a terminal box. It switches compressed air between the two sides of double-acting cylinders and actuators: energise the solenoid and the spool shifts; cut the signal and an internal spring snaps the valve back to its rest position, sending the cylinder back to a known state every cycle.
Flow capacity sits at the top of the 4V range with an effective area of 48 mm2 (Cv 2.82), a solid match for bores of roughly 80-125 mm. The -AM suffix means an AMISCO (Italian) solenoid coil is factory-fitted in place of the standard AirTAC coil; the pneumatic side is untouched, so the valve still responds in 0.05 s or less and weighs 590 g. Ask us to confirm the exact AMISCO coil electrical rating for your AC110V supply before ordering.
AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) Technical Specifications
| Model | AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | AM |
| Exhaust port | AM |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -AM | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) Is Used
Press and forming cylinders
Sized for 80-125 mm double-acting bores with Cv 2.82, the valve cycles large pressing and forming cylinders up to 3 cycles per second, with the spring guaranteeing a retract on every loss of signal.
Heavy clamping fixtures
On machining and welding fixtures, the single-solenoid layout de-energises to a defined rest position, so the clamp side returns predictably whenever the AC110V control signal drops out.
Bulk material handling
Gate, stopper and diverter actuators on conveying lines get fast, positive reversal from the 48 mm2 effective area, and the terminal box keeps wiring simple in panel-controlled plants.
Is the AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) the Right Valve?
Step up to this body when a 4V300 (Cv 1.65) is too small to move your cylinder at the speed you need; the 4V400 is the biggest valve in the 4V family, so for flow beyond Cv 2.82 the route is a larger series or an integrated manifold group on a base. A single solenoid with spring return is the right pick when the circuit must fall back to a defined position on power loss; if you need the actuator to hold its last pulsed state instead, look at the double-solenoid 4V420. For a like-for-like replacement, match all five points: 4V400 body, function 10 (single 5/2), 1/2 inch port in PT thread, AC110V coil, terminal entry.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15 Solenoid Valve, 4V400 Series (4V41015C-AM) FAQ
It is a 5/2-way valve for double-acting cylinders and actuators only. With an effective area of 48 mm2 (Cv 2.82) and a 3 cycle/second maximum frequency, it suits bores of approximately 80-125 mm, running on 0.15-0.8 MPa of filtered air.
The -AM option means the valve leaves the factory with an AMISCO (Italian) solenoid coil fitted instead of the standard AirTAC coil; the body, spring-return function and 1/2 inch PT ports are identical. Our published data does not list the AMISCO coil's VA rating, so please confirm the exact rating with us for your AC110V supply.
