AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI)
The AirTAC AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) is a genuine 5/2-way single solenoid (spring return) solenoid valve with 41015FI ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/2-way
- FunctionSingle solenoid (spring return)
- Port size41015FI
- Effective area48.0 mm²
- Flow (Cv)2.82
- Series4V400
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI)
The 4V410-15FI is a single-solenoid, 5/2-way pneumatic directional valve engineered to command double-acting cylinders and actuators on large-bore machinery. It requires a continuous DC12V electrical signal to hold the shifted position; de-energising the coil allows the internal return spring to instantly drive the spool back to its home state, making it a safe default for applications where the cylinder must retract or stop on power loss.
This specific configuration ships with a grommet-style electrical entry—a 0.5 m pre-wired flying lead that simplifies DIN-connector-free installation in tight cabinets—and a 2.5 W DC12V coil that keeps control-panel heat low. With an effective area of 48.0 mm² (Cv 2.82) and a response time at or below 0.05 s, the valve delivers the crisp, high-flow shifts expected from the largest 4V body, suiting cylinders approximately Ø80–125 mm.
AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) Technical Specifications
| Model | AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Single solenoid (spring return) |
| Port size | 41015FI |
| Exhaust port | 41015FI |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 590 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI)
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 1 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -41015FI | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) Is Used
Mobile Hydraulic-Tail Lift Actuation
Powers the pneumatic-over-hydraulic pilot on truck tail lifts where the vehicle’s 12 V DC electrical system is the only available supply. The grommet lead withstands vibration and moisture far better than a rigid terminal box.
Large-Format CNC Dust Extraction Gates
Cycles a Ø100 mm double-acting gate cylinder to open and close extraction ducts on CNC routers. The spring return guarantees the gate fails closed on E-stop, containing debris, while the 2.5 W coil avoids overheating in continuous-duty panels.
Agricultural Implement Air Clutches
Engages a pneumatic clutch on a tractor-drawn baler or seeder, fed directly from the tractor’s 12 V battery. The pre-wired flying lead connects straight to the ISOBUS connector without an intermediate junction box, cutting installation time.
Is the AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) the Right Valve?
Choose the 4V410-15FI when your double-acting cylinder falls in the Ø80–125 mm range and your control system runs on a 12 V DC supply with limited space for a terminal box. The grommet lead-out eliminates a separate DIN connector and speeds up wiring on mobile or compact equipment. If your cylinder is smaller (Ø40–63 mm), stepping down to a 4V300-series valve with Cv ~1.65 often yields a better cost-to-flow match and reduces manifold footprint.
For replacement, match five points: the 4V400 body size, the 5/2 single-solenoid function, the 1/2 in. port with PT thread, the DC12V coil voltage, and the grommet electrical entry. Substituting a terminal-box version or a different voltage will alter the wiring layout and coil characteristics, so keep the full SKU identical to avoid rework.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
AirTAC 4V410-15FI Solenoid Valve, 5/2-way, PT1/2, DC12V, grommet entry (4V41015FI) FAQ
With an effective area of 48.0 mm² (Cv 2.82), it provides ample flow for double-acting cylinders roughly Ø80–125 mm at typical industrial speeds. For smaller cylinders (Ø50–63 mm) a 4V300 valve is usually more economical, while cylinders above Ø125 mm may need a larger valve series or a parallel manifold to meet the flow demand.
The ‘FI’ suffix gives you a DC12V coil (2.5 W power draw) and a grommet-style entry with a 0.5 m flying lead instead of a terminal box. This is ideal for 12 V mobile or battery-backed systems and for installations where a DIN connector would be too bulky. The valve’s pneumatic performance—48.0 mm² effective area, ≤0.05 s response—remains identical to any other 4V410-15 variant.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
