Airtac JSI Series Standard Cylinder JSI100X1000
The AirTAC Airtac JSI Series Standard Cylinder JSI100X1000 is a genuine double acting JIS-standard air cylinder with a Ø100mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSI Series Standard Cylinder JSI100X1000
Delivering 3927 N of push force at 0.5 MPa, the AirTAC JSI100X1000 is a JIS-standard double-acting profile cylinder built for heavy-duty automation. Its extruded hard-anodized aluminum barrel omits external rods, making the unit shorter and more compact than an ISO 15552 cylinder of the same 100 mm bore. The internal two-way piston seal retains grease for long, low-friction life. Because this SKU lacks the -S magnet, it cannot accept CMSE or DMSE position switches.
For practical sizing, plan for about 2356 N of real work at 0.5 MPa, which safely lifts a 200 kg load vertically with a 2:1 margin. The G1/2 port feeds the 32 mm rod, and adjustable 33 mm air cushions at both ends decelerate the piston smoothly. For a double-rod or adjustable-stroke setup, consider the related JSID or JSIJ types.
Airtac JSI Series Standard Cylinder JSI100X1000 Technical Specifications
| Model | Airtac JSI Series Standard Cylinder JSI100X1000 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSI Series Standard Cylinder JSI100X1000
| JSI | JIS-standard profile cylinder (double-acting type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSI Series Standard Cylinder JSI100X1000 Is Used
Automotive Press Transfer
Moves 180 kg stamping dies between press stations, utilizing the 3927 N push force to shuttle heavy metal blanks reliably.
Pallet Accumulation Stop
Halts fully loaded 1-meter pallets on a packaging line, where the 1000 mm stroke provides ample reach across the conveyor width.
Vertical Lift Gate Actuation
Raises and lowers large loading dock gates, using the long stroke to achieve the full 1-meter opening height required for forklift access.
Is the Airtac JSI Series Standard Cylinder JSI100X1000 the Right Cylinder?
When sizing this 100 mm bore, verify if the 80 mm class (3518 N push at 0.7 MPa) suffices, or step up to the 125 mm bore (6136 N push at 0.5 MPa) for heavier loads. Since this is a 1000 mm stroke, external guide rails are strongly recommended to prevent rod bending and absorb side loads. Remember that a standard cylinder drifts when air is lost or the valve is centered; the air cushion only decelerates the piston near stroke end and will not hold a load. For vertical applications, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSI Series Standard Cylinder JSI100X1000 FAQ
At 0.5 MPa it provides 3927 N push and 3574 N pull; at 0.7 MPa it delivers 5497 N push and 5003 N pull. The theoretical maximum force is 801 kgf at 1.0 MPa. It uses a G1/2 air port and an M26x1.5 rod-end thread.
The JSI is a JIS-standard profile cylinder that is shorter and more compact than an ISO 15552 cylinder of the same 100 mm bore, saving valuable machine space. Note that this specific SKU lacks the -S magnet, so it cannot support CMSE or DMSE sensors.
