Airtac JSI Series Standard Cylinder JSI100X110
The AirTAC Airtac JSI Series Standard Cylinder JSI100X110 is a genuine double acting JIS-standard air cylinder with a Ø100mm bore and 110mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke110 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSI Series Standard Cylinder JSI100X110
Delivering 3927 N of push force at 0.5 MPa, the AirTAC JSI100X110 is a robust double-acting JIS-standard profile cylinder built for heavy machinery. Its extruded hard-anodized aluminum barrel omits external rods, making the unit significantly shorter and more compact than an ISO 15552 cylinder of the same 100 mm bore. The internal two-way piston seal retains grease, ensuring low-friction operation over a long service life.
Because this specific SKU lacks the -S magnet suffix, it cannot accept CMSE or DMSE position switches. For real-world sizing, plan for about 2356 N of actual work at 0.5 MPa, which translates to lifting roughly 200 kg vertically with a 2:1 safety margin. The cylinder features a 32 mm carbon steel rod, M26x1.5 rod-end threading, and a G1/2 air port.
Airtac JSI Series Standard Cylinder JSI100X110 Technical Specifications
| Model | Airtac JSI Series Standard Cylinder JSI100X110 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSI Series Standard Cylinder JSI100X110
| JSI | JIS-standard profile cylinder (double-acting type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSI Series Standard Cylinder JSI100X110 Is Used
Injection Mold Clamping
Supplies the 3927 N push force required to secure mid-sized injection mold halves during material injection cycles.
Heavy Pallet Diverter
Pushes loaded pallets weighing up to 200 kg onto secondary packaging lines using the 110 mm stroke extension.
Press Ejection System
Cycles finished metal stampings out of a 100-ton press bed, utilizing the hard-anodized barrel for wear resistance.
Is the Airtac JSI Series Standard Cylinder JSI100X110 the Right Cylinder?
When sizing this 100 mm bore model, consider the adjacent JSI series options: stepping down to the 80 mm bore yields 2513 N of push force at 0.5 MPa, while moving up to the 125 mm bore provides 6136 N. At 110 mm, the stroke is well within standard limits, so no complex side-load guides are strictly necessary, though standard mountings like LB foot, FA/FB flange, or TC trunnion are available. Note that air loss will cause the piston to drift, as the end cushions only decelerate the stroke and do not act as a brake; install an external rod lock for suspended loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSI Series Standard Cylinder JSI100X110 FAQ
This 100 mm bore cylinder features a G1/2 air port and an M26x1.5 rod thread. It generates 3927 N push and 3574 N pull at 0.5 MPa, 5497 N push and 5003 N pull at 0.7 MPa, with a theoretical maximum of 801 kgf at 1.0 MPa.
The JSI100X110 is a JIS-standard profile cylinder that is shorter and more compact than an ISO 15552 cylinder of the same bore, saving valuable machine space. Also, because this SKU lacks the -S suffix, it has no magnet and cannot host CMSE or DMSE sensors.
