Airtac JSI Series Standard Cylinder JSI100X125S
2. Features profiled bidirectional sealing structure with compact dimensions and integrated oil reservoir for piston lubrication;
3. JSI Series utilizes cross-braced aluminum alloy tubing with tie-rod-free design, offering superior corrosion resistance;
4. Reduced overall length compared to ISO15552 standard cylinders of equivalent bore size;
5. Precision-adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive selection of bore sizes and mounting accessories available for customized system integration.
Category: Standard Cylinders, Brand: AirTAC, Series: JSI
AirTAC JSI Standard Cylinder JSI100X125S Technical Details
- Series: JSI Standard Round Cylinder
- Bore size: 100mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic foot mounting (ISO 15552 compatible)
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–750 mm/s
- Ambient temperature: -20℃ to 80℃
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR (standard), optional FKM for high temp
- Protection class: IP54 (standard), IP67 optional
- Weight: 3.8 kg (excluding accessories)
- Dimensions:
- Extended length: 310mm
- Retracted length: 185mm
- Body diameter: 100mm
- Mounting hole spacing: 160mm (front flange)
High-performance ISO-compliant pneumatic cylinder featuring precision honed tube and wear-resistant seals. The dual cushion design minimizes end-impact noise while maintaining positioning accuracy. Optional magnetic piston version (JSI100X125S-M9) available for position sensing. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Press machine ejection systems
- Automated assembly line clamping
- Foundry equipment actuation
- Packaging machinery pushers
- Food processing conveyor gates
Maintenance tip:
Lubricate every 3,000km of stroke travel or 6 months (whichever comes first).
Use only AirTAC-recommended grease (PN: ALG-2) for seal compatibility.
| Property | Property Value |
|---|---|
| sku | JSI100X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | 29mm |
| Bore Diameter | 100mm |
| Stroke | 125mm |
