Airtac JSI Series Standard Cylinder JSI100X130
The AirTAC Airtac JSI Series Standard Cylinder JSI100X130 is a genuine double acting JIS-standard air cylinder with a Ø100mm bore and 130mm stroke, G1/2 air ports and adjustable end cushioning. Its no-tie-rod, hard-anodized profile barrel is more compact than an ISO 15552 cylinder of the same bore — a space-saver on tight machines.
- BoreØ100 mm
- Stroke130 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM26×1.5
- CushionAdjustable, 33 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac JSI Series Standard Cylinder JSI100X130
Delivering 3927 N of push force at 0.5 MPa, this double-acting 100 mm bore JIS-standard profile cylinder is built for heavy-duty automation. It is intentionally shorter and more compact than an equivalent ISO 15552 cylinder of the same bore, saving valuable machine space without sacrificing power. The extruded hard-anodized aluminum barrel eliminates external rods to resist wear, while the two-way piston seal retains grease for a long, low-friction service life.
For practical sizing, plan for about 2356 N of real work at 0.5 MPa, which safely lifts about 200 kg vertically with a 2:1 margin. The unit features a 32 mm carbon steel rod, a G1/2 air port, and 33 mm adjustable air cushions at both ends to smooth out deceleration. Because this specific SKU lacks the -S magnet, it cannot accept CMSE or DMSE position switches without upgrading to the sensed variant.
Airtac JSI Series Standard Cylinder JSI100X130 Technical Specifications
| Model | Airtac JSI Series Standard Cylinder JSI100X130 |
|---|---|
| Series | JSI JIS-standard profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M26×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 33 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC JSI (JIS standard) datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G. Barrel: hard-anodized aluminum profile (no tie rods).
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac JSI Series Standard Cylinder JSI100X130
| JSI | JIS-standard profile cylinder (double-acting type). |
|---|---|
| 100 | Bore size in mm (32 / 40 / 50 / 63 / 80 / 100 / 125). |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensors. |
JSI-family variants: JSI (double acting), JSID (double rod), JSIJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / TCM1 / TCM2. Thread PT (blank) / G.
Where the Airtac JSI Series Standard Cylinder JSI100X130 Is Used
Injection Mold Clamping
Provides the heavy 3927 N push force required to secure mid-sized injection mold halves during material injection cycles.
Pallet Stopper Gate
Acts as a robust 130 mm stroke barrier to halt loaded pallets weighing up to 200 kg on a high-speed packaging conveyor.
Automated Guided Vehicle Lift
Raises and lowers heavy transmission housings on an AGV, utilizing the compact profile to fit within tight chassis dimensions.
Is the Airtac JSI Series Standard Cylinder JSI100X130 the Right Cylinder?
When sizing this 100 mm bore unit, verify your force margins against its neighbors: a 63 mm bore provides 1559 N push at 0.5 MPa, while the largest 125 mm bore offers 6136 N. If your machine experiences air loss or the valve is centered, be aware that the piston will drift and the end cushions only decelerate the stroke near the ends rather than locking the load. To hold a suspended weight securely, integrate an external rod lock or a pilot-operated check valve. You can mount this cylinder using LB foot, FA/FB flange, CA/CB/CR clevis, or TC/TCM1/TCM2 trunnion brackets, plus an I, Y, F, or U rod knuckle.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac JSI Series Standard Cylinder JSI100X130 FAQ
At 0.5 MPa it provides 3927 N push and 3574 N pull. At 0.7 MPa it provides 5497 N push and 5003 N pull. The theoretical maximum force is 801 kgf at 1.0 MPa. It operates at 30-800 mm/s, uses a G1/2 port, and has a 32 mm rod with an M26x1.5 thread.
The JSI is a JIS-standard profile cylinder that is shorter and more compact than an ISO 15552 cylinder of the same 100 mm bore. It uses an extruded hard-anodized aluminum barrel without external rods, but it is not dimensionally interchangeable with ISO 15552 footprints.
