Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA
The AirTAC Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA is a genuine double acting JIS-standard round-body mini air cylinder with a Ø32mm bore and 100mm stroke, 1/4" air ports and a SUS304 stainless-steel barrel for mildly corrosive environments. For the same bore and stroke it is shorter than an ISO 6432 cylinder, saving mounting space.
- BoreØ32 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA
Generating 402.2 N of push force at 0.5 MPa, this double-acting AirTAC MF32X100SCA mini cylinder features a 32 mm bore and a 100 mm stroke. The JIS-standard round-body design is physically shorter than a comparable ISO 6432 cylinder, saving valuable mounting length in tight machinery. Because the base SKU includes an -S magnet, it is fully compatible with CMSG, DMSG, and EMSG reed or electronic switches for position sensing.
The SUS304 stainless steel barrel and riveted aluminium covers resist mild corrosion and washdown environments. Fixed TPU bumper pads and a front-cover anti-impact pad soften stroke-end impact, though they only decelerate rather than provide adjustable cushioning. For practical sizing, plan for a safe working load of roughly 241 N, which means it can vertically lift about 20.5 kg with a 2:1 safety margin. The 1/4 inch port and M10x1.25 male rod thread accommodate robust pneumatic flow for this force class.
Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA Technical Specifications
| Model | Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA |
|---|---|
| Series | MF JIS mini cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MF/MFC (JIS-standard) datasheet. Barrel: SUS304 stainless steel; covers: aluminum alloy (round-body, riveted rolling-packed construction). Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | 484 N |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA
| MF | JIS-standard round-body mini cylinder (double-acting). |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MF-family variants: MF / MFC (double acting ±cushion), MSF / MTF (single acting push / pull), MFD / MFCD (double rod ±cushion), MFJ / MFCJ (adjustable stroke ±cushion). Back covers CA / U / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA Is Used
Package Diverting Arm
Actuates a routing gate on a packaging line, using the 100 mm stroke to push cartons onto secondary tracks without stalling the main belt flow.
Clamp Mechanism
Secures aluminium extrusions during CNC machining operations, applying steady 402.2 N clamping pressure at 0.5 MPa to prevent workpiece vibration.
Pallet Stopper Gate
Functions as a pneumatic stop in a low-profile roller conveyor system, holding loaded pallets in place for robotic wrapping before releasing them downstream.
Is the Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA the Right Cylinder?
When sizing this 32 mm bore unit, consider the MF25 which provides 245.3 N of push force at 0.5 MPa, or step up to the MF40 delivering 628.3 N if your application requires heavier movement. This model features a CA pivot back cover, making it ideal for clevis mounting configurations that accommodate angular rod movement. If your mechanism must maintain its vertical position during a compressed air loss or when the directional valve is centered, be aware that the piston will drift. You should integrate an external pilot-operated check valve or a dedicated rod lock to secure the load.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MF32-40 Stainless Steel Mini Cylinder MF32X100SCA FAQ
At 0.5 MPa, the push force is 402.2 N and the pull force is 345.6 N. At 0.7 MPa, it pushes 563 N and pulls 483.8 N. The theoretical maximum force is 82 kgf at 1.0 MPa. This 32 mm bore cylinder uses a 1/4 inch port and an M10x1.25 male rod thread.
No, the piston will drift if air is lost or the valve is centered, as the fixed TPU bumper pads only decelerate the stroke end and do not act as a brake. To maintain a vertical load, you must install an external rod lock or a pilot-operated check valve.
