Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA
The AirTAC Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA is a genuine double acting + cushion JIS-standard round-body mini air cylinder with a Ø20mm bore and 10mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel for mildly corrosive environments. For the same bore and stroke it is shorter than an ISO 6432 cylinder, saving mounting space.
- BoreØ20 mm
- Stroke10 mm
- Port size1/8"
- Acting typeDouble acting + cushion
- Rod threadM8×1.25
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA
Delivering 157 N of push force at 0.5 MPa, this double-acting 20 mm bore mini cylinder relies on a needle-set variable air cushion at both ends to soak up high-speed end-of-stroke shock. The riveted aluminium covers and SUS304 stainless barrel resist mild corrosion and washdown environments. Because the -S suffix equips the piston with a magnet, you can mount CMSG, DMSG or EMSG switches for position sensing.
For the same bore and stroke, the JIS-standard round-body housing is noticeably shorter than an ISO 6432 cylinder, saving valuable mounting length. Driven by a 1/8 inch air port, it yields a safe working load of roughly 94 N and lifts about 8 kg vertically with a 2:1 margin. The CA rear pivot cover simplifies angular alignment on your machine frame.
Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA Technical Specifications
| Model | Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA |
|---|---|
| Series | MFC JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 10 mm |
| Acting type | Double acting + cushion |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MF/MFC (JIS-standard) datasheet. Barrel: SUS304 stainless steel; covers: aluminum alloy (round-body, riveted rolling-packed construction). Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 157 N | 132 N |
| 0.7 MPa | 220 N | 185 N |
| Max (@1.0 MPa) | 32 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA
| MFC | JIS-standard round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 20 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MF-family variants: MF / MFC (double acting ±cushion), MSF / MTF (single acting push / pull), MFD / MFCD (double rod ±cushion), MFJ / MFCJ (adjustable stroke ±cushion). Back covers CA / U / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA Is Used
Small Parts Ejection
Shoots lightweight plastic components out of a machining zone at speed, relying on the needle-set air cushion to prevent end-of-stroke bounce.
Package Deflection
Pushes small cartons onto a secondary belt; the SUS304 riveted body handles occasional splash during washdown cycles.
Compact Gripper Actuation
Fits into tight robotic end-effectors where overall length is critical, providing 8 kg of vertical lift with a 2:1 safety margin.
Is the Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA the Right Cylinder?
If 94 N of safe working load is insufficient, step up to the MFC25 which provides 245.3 N at 0.5 MPa; there is no smaller MFC bore, so this 20 mm variant is the floor of the range. The adjustable air cushion is essential when cycling at high speeds or moving sensitive masses, as it decelerates the piston near stroke end without harsh impacts. Remember that this cylinder does not hold position on air loss—the piston will drift—so fit an external rod lock or pilot check valve if you need to secure a suspended load. Along with the CA back pivot, you can use LB foot, FA flange, SDB pivot or TC trunnion mounts to suit your layout.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10SCA FAQ
This 20 mm bore cylinder uses a 1/8 inch port and an M8x1.25 male rod thread. It generates 157 N push and 131.9 N pull at 0.5 MPa, 219.8 N push and 184.7 N pull at 0.7 MPa, with a theoretical maximum of 32 kgf at 1.0 MPa.
No, the piston will drift on air loss. The variable air cushion only decelerates the piston near the stroke end; it is not a brake. For suspended loads, install an external rod lock or pilot check valve. The built-in -S magnet supports CMSG, DMSG and EMSG sensors.
