Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA
The AirTAC Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA is a genuine double acting round-body mini air cylinder with a Ø10mm bore and 105mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ10 mm
- Stroke105 mm
- Port sizeM5×0.8
- Acting typeDouble acting
- Rod threadM4×0.7
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA
Delivering 39.3 N of push force at 0.5 MPa, this double-acting stainless-steel round-body mini cylinder handles compact linear tasks. The Ø10 mm bore uses an M5x0.8 air port and an M4x0.7 male rod thread. Its stainless barrel and rod resist mild corrosion, giving it a real edge over painted-steel alternatives in damp or washdown environments. The built-in magnet (-S) supports CMSG, DMSG and EMSG position switches.
For practical sizing, plan for about 24 N of actual work at 0.5 MPa, which safely lifts a 2 kg part vertically with a 2:1 margin. The riveted body keeps the unit light, while fixed TPU bumper pads absorb the impact at stroke end. Because it conforms to ISO 6432 mounting dimensions, the body drops directly into standard mini-cylinder brackets and clevises.
Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA Technical Specifications
| Model | Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA |
|---|---|
| Series | MI ISO 6432 mini cylinder |
| Bore size | Ø10 mm |
| Stroke | 105 mm |
| Acting type | Double acting |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 200 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø10mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 39 N | 33 N |
| 0.7 MPa | 55 N | 46 N |
| Max (@1.0 MPa) | 8 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA
| MI | ISO 6432 round-body mini cylinder (double-acting). |
|---|---|
| 10 | Bore size in mm. |
| ×105 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA Is Used
PCB Component Placement
Pushes small electronic parts into sockets on automated assembly lines using a precise 39.3 N push force at 0.5 MPa.
Blister Pack Sorting
Diverts lightweight pharmaceutical blister packs along a guide rail, relying on the stainless body for cleanroom washdown compatibility.
Small Parts Gate
Actuates a deflector gate on a conveyor to separate 2 kg plastic housings, utilizing the CA pivot clevis for smooth articulation.
Is the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA the Right Cylinder?
When sizing this 10 mm bore, step down to the Ø8 model for lighter duties (18.8 N pull at 0.5 MPa) or move up to the Ø12 bore if you need more power (56.5 N push at 0.5 MPa). This 105 mm stroke sits well within the 200 mm maximum standard stroke for this bore, but at this length you should still minimize side-loading to prevent rod bending. The CA rear pivot cover suits articulated clevis mounting.
Note that a standard double-acting cylinder drifts when air is lost or the valve is centered, as the fixed TPU pads only decelerate the stroke end rather than locking the load. To hold a vertical position securely, add an external rod lock or a pilot-operated check valve. The integrated magnet allows seamless sensor tracking.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MI8~12 Stainless Steel Mini Cylinder MI10X105SCA FAQ
At 0.5 MPa, the push force is 39.3 N and the pull force is 33 N. At 0.7 MPa, push is 55 N and pull is 46.1 N. The theoretical maximum force is 8 kgf at 1.0 MPa. The air port is M5x0.8.
No, the base MI features fixed TPU bumper pads that decelerate the stroke end, not an adjustable air cushion (see the MIC variant for that). However, the -S magnet in this model fully supports CMSG, DMSG and EMSG electronic or reed switches.
