Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA
The AirTAC Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA is a genuine double acting round-body mini air cylinder with a Ø10mm bore and 130mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ10 mm
- Stroke130 mm
- Port sizeM5×0.8
- Acting typeDouble acting
- Rod threadM4×0.7
- CushionFixed TPU bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA
Delivering 39.3 N of push force at 0.5 MPa, this double-acting stainless-steel round-body mini cylinder handles compact automation tasks with ease. The riveted barrel and rod shrug off mild corrosion, making it far superior to painted alternatives in damp or washdown environments. Because this SKU includes the -S magnet, it is fully ready for CMSG, DMSG or EMSG position switches.
The Ø10 mm bore uses an M5x0.8 air port and an M4x0.7 male rod thread. It conforms to ISO 6432 mounting dimensions, so it drops directly into standard mini-cylinder brackets. For real-world sizing, plan for a safe working load of about 24 N, which means it lifts roughly 2 kg vertically with a 2:1 safety margin. Fixed TPU bumper pads absorb the impact at stroke end to protect your mechanism.
Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA Technical Specifications
| Model | Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA |
|---|---|
| Series | MI ISO 6432 mini cylinder |
| Bore size | Ø10 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | M5×0.8 |
| Rod thread | M4×0.7 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed TPU bumper pads |
| Max standard stroke | Up to 200 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø10mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 39 N | 33 N |
| 0.7 MPa | 55 N | 46 N |
| Max (@1.0 MPa) | 8 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA
| MI | ISO 6432 round-body mini cylinder (double-acting). |
|---|---|
| 10 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA Is Used
Textile Yarn Guides
Shifts lightweight thread guides across a 130 mm path; the stainless build resists humid dye-house atmospheres.
Pouch Sealing Jaws
Actuates small sealing jaws with a 39.3 N push at 0.5 MPa, while the CA rear clevis handles the pivoting jaw motion.
Lab Sample Ejection
Pushes test tubes out of a carousel with a safe 24 N working load, using the -S magnet to confirm ejection via a DMSG sensor.
Is the Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA the Right Cylinder?
When sizing this actuator, compare it against its neighbours: the smaller Ø8 bore yields 25.1 N of push at 0.5 MPa, while the larger Ø12 provides 56.5 N. If your task needs less than 25 N, step down to the Ø8; if you exceed 40 N, move up to the Ø12. This 130 mm stroke sits well within the 200 mm standard limit for this bore, but at this length you should watch for side loads that could bend the Ø4 mm rod. The built-in CA pivot clevis on the back cover is ideal for accommodating slight misalignment on swinging mechanisms. Note that air pressure alone will not hold a load if supply drops—the piston will drift, so fit a pilot-operated check valve if you need static positioning.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MI8~12 Stainless Steel Mini Cylinder MI10X130SCA FAQ
At 0.5 MPa it pushes 39.3 N and pulls 33 N. At 0.7 MPa it pushes 55 N and pulls 46.1 N. The theoretical maximum force is 8 kgf at 1.0 MPa. The air port is M5x0.8 and the male rod thread is M4x0.7.
No, the piston will drift if air pressure is lost or the valve is centred. The fixed TPU bumper pads only decelerate the stroke end; they do not act as a brake. You must add an external rod lock or pilot check valve to hold a suspended load.
