Airtac SAI100 Standard Air Cylinder SAI100AX140S
The AirTAC Airtac SAI100 Standard Air Cylinder SAI100AX140S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø100mm bore and 140mm stroke, G1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ100 mm
- Stroke140 mm
- Port sizeG1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SAI100 Standard Air Cylinder SAI100AX140S
The AirTAC SAI100X140-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty automation. Delivering a robust 5497 N push force at 0.7 MPa, this 100mm bore unit is built to handle substantial loads across its 140mm stroke. The extruded aluminum barrel design omits tie-rods, providing a clean exterior that simplifies sensor mounting and machine integration.
This specific configuration includes a SUS420J2 stainless steel piston rod (material code A) for enhanced corrosion resistance in humid or mildly chemically washed environments. Equipped with a magnet (-S), it seamlessly interfaces with CMSE and DMSE series reed switches fitted into the dual-side sensor grooves. Standard adjustable air cushions at both ends ensure smooth deceleration of heavy payloads.
Airtac SAI100 Standard Air Cylinder SAI100AX140S Technical Specifications
| Model | Airtac SAI100 Standard Air Cylinder SAI100AX140S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø100 mm |
| Stroke | 140 mm |
| Acting type | Double acting |
| Port size | G1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAI100 Standard Air Cylinder SAI100AX140S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×140 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAI100 Standard Air Cylinder SAI100AX140S Is Used
Heavy Material Handling
Ideal for lifting and transferring heavy pallets or metal sheets where the 5497 N push force at 0.7 MPa easily manages substantial dead weights.
Pressing and Stamping
Provides consistent, high-force pressing action for light assembly tasks, bearing insertion, or metal forming operations within a compact 140mm stroke.
High-Capacity Diverting
Suitable for actuating heavy-duty diverter arms or sorting gates on high-throughput conveyor lines, utilizing the adjustable cushions to cushion stop impacts.
Is the Airtac SAI100 Standard Air Cylinder SAI100AX140S the Right Cylinder?
Choosing this 100mm bore is ideal when 80mm cylinders (providing 3518 N push at 0.5 MPa) lack the necessary thrust for high-inertia loads. If your application requires less force and faster cycling, stepping down to an 80mm bore optimizes air consumption. Because the SAI100X140-S is a double-acting actuator, it cannot hold a load in place if air pressure drops completely; for fail-safe load holding, consider the SAIL variant with an air-released lock or the BSAI clamp-lock cylinder.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a drop-in replacement for other ISO 15552 profile cylinders without requiring custom mounting plates. To complete your setup, pair this 140mm stroke unit with PT threaded ports, FA/FB flanges or TC trunnion brackets, and CMSE/DMSE sensors to utilize the built-in magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAI100 Standard Air Cylinder SAI100AX140S FAQ
At an operating pressure of 0.7 MPa, the SAI100X140-S generates a push force of 5497 N and a pull force of 3681 N. The theoretical maximum force at 1.0 MPa is 801 kgf.
Yes, the SAI100X140-S includes a built-in magnet (-S) and features dual sensor grooves on the extruded barrel, making it fully compatible with CMSE and DMSE series switches.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models usually ship in 3-4 days.
Fast Reply
Most inquiries answered within 7-8 hours.
