Airtac SDA Ultra Thin Cylinder SDA80X35
The AirTAC Airtac SDA Ultra Thin Cylinder SDA80X35 is a genuine double-acting COMPACT (thin) air cylinder with a Ø80mm bore and 35mm stroke, PT3/8 air ports and a riveted short body that saves mounting depth. Sensor slots around the body accept magnetic switches for position sensing.
- BoreØ80 mm
- Stroke35 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM14×1.5 (F) / M22×1.5 (B)
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDA Ultra Thin Cylinder SDA80X35
The AirTAC SDA80X35 is a double-acting, single-rod compact cylinder engineered to deliver a robust 2513.3 N push force at 0.5 MPa. Its riveted assembly joins the barrel, rear cover, piston, and 25 mm rod into a highly abbreviated unit, drastically reducing axial mounting depth compared to conventional round-body actuators. This space efficiency is critical when designing large-bore actuation into tight machine footprints.
This specific configuration features a 35 mm stroke and a PT3/8 port. Instead of an adjustable air cushion, the piston strikes a fixed NBR bumper at each end to decelerate the stroke. Because this SKU lacks the S option, it has no piston magnet and cannot support position sensing; adding the -S variant enables the use of reed or electronic switches in the body grooves.
Airtac SDA Ultra Thin Cylinder SDA80X35 Technical Specifications
| Model | Airtac SDA Ultra Thin Cylinder SDA80X35 |
|---|---|
| Series | SDA compact (thin) cylinder |
| Bore size | Ø80 mm |
| Stroke | 35 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod end thread | M14×1.5 female / M22×1.5 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
| Max standard stroke | Up to 120 mm |
Specifications follow the official AirTAC SDA compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard). Rod: female thread (blank) / male thread (B).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SDA Ultra Thin Cylinder SDA80X35
| SDA | Compact (thin) double-acting cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×35 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| B | Male-thread piston rod (omit = female-thread rod). |
Thread: PT standard. Related SDA-family variants: SSA (single-acting push), STA (single-acting pull), SDAD (double rod), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDA Ultra Thin Cylinder SDA80X35 Is Used
Injection Mold Ejection
Provides the high 2513.3 N push force required to eject dense plastic parts from injection molding tools where short overall length prevents interference with the press platen.
Heavy Press Brake Gauging
Positions back-gauge stops on heavy sheet metal press brakes, utilizing the 25 mm rod to withstand substantial lateral resistance during plate alignment.
Pallet Flap Folding
Folds heavy cardboard flaps on automated palletizing lines, delivering rapid 35 mm strokes that cycle continuously at speeds between 30 and 500 mm/s.
Is the Airtac SDA Ultra Thin Cylinder SDA80X35 the Right Cylinder?
When sizing this 80 mm bore actuator, evaluate your force requirements carefully. Stepping down, the SDA63 provides 1558.6 N of push at 0.5 MPa, while stepping up to the SDA100 yields 3927 N at the same pressure. For the SDA80X35, a safe working load is approximately 1508 N (60% of the 0.5 MPa figure), translating to a vertical lift capacity of about 128.1 kg with a 2:1 safety margin.
Remember that a standard double-acting cylinder drifts when air pressure is lost or the valve is centered, as the fixed bumper only decelerates the piston near stroke end rather than locking it. To hold a load securely without live pressure, you must integrate an external rod lock or a pilot-operated check valve. To order, confirm the 80 mm bore, 35 mm stroke, PT3/8 port, female M14x1.5 rod thread, and the absence of a magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short-body depth vs. a round-body cylinder
- ✓ Port/thread type (PT)
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
- ✓ Side load — avoid on a compact rod
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the short piston rod.
- check Very long strokes are unsuitable for the compact body.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDA Ultra Thin Cylinder SDA80X35 FAQ
This 80 mm bore double-acting cylinder generates 2513.3 N of push and 2267.8 N of pull at 0.5 MPa. At 0.7 MPa, push increases to 3518.6 N. The theoretical maximum push force is 513 kgf at 1.0 MPa, with a proof pressure of 1.5 MPa.
No adjustable air cushion exists; the cylinder relies on fixed NBR bumpers to decelerate the stroke end, so external shock absorbers are advised for high-energy loads. Additionally, this specific SKU lacks a piston magnet, meaning it cannot accept reed or electronic switches unless upgraded to the S option.
