Airtac 100M Solenoid Valve Manifold 100M-1F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-1F Solenoid Valve Base Specifications
- Model: 100M-1F
- Type: Modular valve manifold base
- Material: Reinforced black PBT (30% glass fiber)
- Port size: G1/8 (ISO228 standard)
- Compatible valves: 100M series solenoid valves
- Max pressure: 1.0 MPa
- Temperature range: -5℃ to 80℃
- Weight: 198g ±3g
- Dimensions: 52mm(L) × 32mm(W) × 24mm(H)
- Sealing method: Metal-free seal structure
- Port configuration: 1 input (IN), 2 outputs (OUT1/OUT2)
- Surface finish: V-2 flame retardant rating
- Mounting: DIN rail or direct screw mounting
High-density modular base designed for multi-valve stacking in compact pneumatic systems. Features integrated flow channels with optimized pressure drop characteristics (ΔP≤0.02MPa at 5L/min). Anti-vibration design prevents loosening under 5-200Hz mechanical stress.
- Multi-station pneumatic control panels
- Automated assembly line manifolds
- Textile machinery air distribution
- Semiconductor handling equipment
- Beverage filling system clusters
Installation note:
Use torque-controlled tightening (1.2-1.5N·m) for manifold stacking.
Apply silicone-free lubricant on sealing surfaces during assembly.
Maximum recommended stack height: 10 units.
| Property | Property Value |
|---|---|
| sku | 100M-1F |
