Airtac 2JS Angle Seat Valve 2JSY15015Q50G
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSY15015Q50G Angle Seat Valve Technical Details
- Model Code: 2JSY15015Q50G
- Valve Type: 2-way normally closed (spring return)
- Port Connection: G1/2" ISO228 standard
- Actuation: Pneumatic pilot operated with manual override
- Operating Pressure Range: 0.1-1.0 MPa
- Max Working Pressure: 10 bar (145 psi)
- Fluid Temperature Range: -5℃ to 80℃ (medium dependent)
- Body Material: Stainless steel CF8M (316 equivalent)
- Seal Materials: HNBR (Hydrogenated Nitrile) standard, FKM optional
- Flow Coefficient (Cv): 4.2 (Kv=3.8)
- Voltage Options: 24VDC (standard), 110VAC/220VAC (customizable)
- Power Consumption: 2.5W @ 24VDC
- Response Time: ≤50ms (actuation to full open)
- Weight: 820g ±3% (without accessories)
- Dimensions: 120mm(L) × 50mm(W) × 70mm(H)
- Protection Class: IP67 (NEMA 4X equivalent)
- Certifications: RoHS compliant, REACH SVHC-free
High-flow angle seat valve with 90° flow path optimization, featuring zero dead volume design for precise fluid control. The stainless steel construction ensures chemical resistance for aggressive media handling. Integrated position indicator and manual test button enable maintenance-friendly operation.
- Steam control in food/beverage CIP systems
- Chemical dosing systems with corrosive liquids
- High-temperature water circulation in textile machinery
- Vacuum line switching in packaging automation
- Coolant control in CNC machining centers
Installation guidelines:
Mount with actuator facing upward for optimal diaphragm life. Use PTFE tape on male threads only.
Requires 5μm filtration upstream. Cycle life exceeds 5 million operations when maintained with
annual seal replacement and quarterly lubrication of sliding parts.
| Property | Property Value |
|---|---|
| sku | 2JSY15015Q50G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
