Airtac 6HV Manifold Solenoid Valve 6HV0500M7F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M7F Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0500M7F
- Type: 5/3-way closed center (pilot-operated)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Flow coefficient (Cv): 0.8
- Response time: ≤20ms (at rated voltage)
- Weight: 300g ±5% (excluding manifold base)
- Dimensions: 70mm(L) × 30mm(W) × 90mm(H) (single valve stack)
- Seal material: NBR/FKM optional (standard NBR)
- Temperature range: -5℃ to 60℃ (fluid/ambient)
- Power consumption: 1.5W (DC24V), 3.2VA (AC220V)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Max operating frequency: 5Hz
- Port thread depth: 12mm (full thread engagement recommended)
High-density manifold-mounted valve designed for multi-valve systems, featuring zero pressure differential operation capability. The stacked design reduces piping complexity by 70% compared to individual valves. Optimized spool structure ensures ≤0.1ms response time consistency between units. Compatible with ISO 15407-1 manifold bases.
- Multi-axis pneumatic actuator control in CNC machines
- Bottle cap sorting & capping automation lines
- Textile machinery tension control systems
- Lithium battery production equipment
- Plastic injection molding EJECTOR circuits
Installation protocol:
Requires ISO G3/4 filtered air (40μm particulate max).
Maximum 20-valve stack recommended.
Apply thread sealant on manifold base screws (2.5Nm torque limit).
Perform monthly seal integrity checks in high-cycle applications (>500k cycles/day).
| Property | Property Value |
|---|---|
| sku | 6HV0500M7F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
