Airtac HD4A Pneumatic Valve HD4A130E
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A130E Pneumatic Valve Technical Specifications
- Model: HD4A130E
- Type: 5/2-way monostable solenoid valve (direct-acting)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Response time: ≤15ms (at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile) / Optional FKM (Viton)
- Ambient temperature: -5℃ to 60℃ (with NBR), -5℃ to 80℃ (with FKM)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Port thread depth: 12mm (minimum engagement)
- Weight: 215g ±5g
- Dimensions: 55mm (L) × 35mm (W) × 70mm (H)
- Protection class: IP67 (dustproof and waterproof)
- Manual override: Built-in push-button actuator
High-flow directional control valve engineered for industrial automation systems requiring rapid cycling. Features dual-pressure capability and shock-resistant coil design with LED status indicator. The hardened stainless steel spool ensures 2 million cycle durability. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Plastic injection molding machine clamp control
- Automated conveyor sorting systems
- CNC machine tool chuck actuators
- Beverage canning line pneumatic circuits
- Automotive tire assembly robots
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 20mm clearance below valve for condensate drainage.
Lubricate air supply with ISO VG32 pneumatic oil if operating below 0.3MPa.
