Airtac HD4A Pneumatic Valve HD4A230E
- Category:
- Pneumatic Control Valves
- Brand:
- AIRTAC
- Series:
- HD4A
The AIRTAC HD4A series represents a premium line of 4-way pneumatic directional control valves engineered for industrial automation systems. Featuring poppet-valve construction with enhanced flow paths, these valves deliver:
- High flow capacity (Cv up to 4.8)
- Low power consumption (0.5W typical)
- Multiple actuation options: solenoid, mechanical, pneumatic pilot
- Compact modular design with ISO 15407-1 compliant interfaces
- Operational pressure range: 0.15-0.7 MPa
- Port sizes: 1/4" to 1" NPT/BSPP
- Fluid compatibility: Filtered dry air (ISO 8573-1:2010 Class 3.4.2)
With IP65 protection rating and -5°C to 80°C operational temperature range, the HD4A series excels in demanding industrial environments requiring precision flow control and high cycling frequency.
AirTAC HD4A230E Pneumatic Valve Technical Specifications
- Model: HD4A230E
- Type: 5-port 3-position closed center (Double solenoid)
- Port size: PT1/4 (G1/4 thread standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1,200 L/min (Cv=2.08) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 120mm(L) × 50mm(W) × 60mm(H)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port alignment: ISO 5599-1 standard
High-flow directional control valve with center-block function, featuring corrosion-resistant aluminum alloy body and manual override. Designed for complex pneumatic circuits requiring mid-position cutoff. Optimized for systems demanding rapid cycling (up to 5Hz) and precise directional control.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Automotive tire mounting equipment
- Food processing conveyor controls
- Robotic material handling systems
Installation requirements:
Mount horizontally with valve axis ±15° tolerance. Use 40μm filtration
with automatic drain. Lubricate with ISO VG32 turbine oil if air line
lubrication not available. Allow 20mm clearance for heat dissipation.
| Property | Property Value |
|---|---|
| sku | HD4A230E |
