Airtac MIC Cushioned Mini Cylinder MIC16X100U
The AirTAC Airtac MIC Cushioned Mini Cylinder MIC16X100U is a genuine double acting + cushion round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MIC Cushioned Mini Cylinder MIC16X100U
Damping high-speed impacts is the core strength of the AirTAC MIC16X100U, a double-acting round-body mini cylinder built with a stainless-steel barrel and rod for mild washdown resistance. It features a needle-set adjustable air cushion at both ends to decelerate the load smoothly, cutting noise and shock compared to a standard bumper unit. A 90-degree U rear cover defines the mounting orientation.
Generating 100.5 N of push force at 0.5 MPa, this 16 mm bore unit handles light loads with a safe working capacity of about 60 N, lifting roughly 5.1 kg vertically with a 2:1 safety margin. It uses an M5×0.8 port and conforms to ISO 6432 mounting dimensions for easy bracket integration. Note this SKU lacks a magnet, so it cannot accept CMSG, DMSG, or EMSG sensors.
Airtac MIC Cushioned Mini Cylinder MIC16X100U Technical Specifications
| Model | Airtac MIC Cushioned Mini Cylinder MIC16X100U |
|---|---|
| Series | MIC ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MIC Cushioned Mini Cylinder MIC16X100U
| MIC | ISO 6432 round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MIC Cushioned Mini Cylinder MIC16X100U Is Used
Light Parts Ejection
Safely kicks small plastic parts out of a mold cavity at speed, using the adjustable cushion to prevent the rod from slamming at the end of the 100 mm stroke.
Package Diverting
Pushes small cartons on a conveyor with a safe working load of 60 N, relying on the stainless build to resist humidity in packing zones.
Component Sorting
Handles the rapid transfer of lightweight electronic components, where the M5×0.8 port ensures fast actuation without harsh end impacts.
Is the Airtac MIC Cushioned Mini Cylinder MIC16X100U the Right Cylinder?
For lighter tasks, the MI12 bumper cylinder offers less force, while stepping up to the MIC20X50 provides 157 N of push at 0.5 MPa if this 100.5 N unit stalls. The adjustable cushion matters most when cycling quickly or moving heavier masses, preventing end-of-stroke banging. Remember the cushion only decelerates; it does not lock the rod. To hold a load vertically on air loss, fit an external rod lock or pilot check valve. Choose the -S variant if you need position sensing, and utilize LB foot or FA flange mounts for this ISO 6432 body.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MIC Cushioned Mini Cylinder MIC16X100U FAQ
This 16 mm bore cylinder uses an M5×0.8 port and delivers 100.5 N push and 86.4 N pull at 0.5 MPa, or 140.7 N push and 120.9 N pull at 0.7 MPa. Its theoretical maximum force is 20.5 kgf at 1.0 MPa.
No, this specific SKU does not include a magnet, so it cannot accept CMSG, DMSG, or EMSG switches. You would need the -S variant for position sensing. The adjustable air cushion at both ends only decelerates the load; it is not a brake.
