Airtac MIC Cushioned Mini Cylinder MIC16X10CM
The AirTAC Airtac MIC Cushioned Mini Cylinder MIC16X10CM is a genuine double acting + cushion round-body mini air cylinder with a Ø16mm bore and 10mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeDouble acting + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MIC Cushioned Mini Cylinder MIC16X10CM
Handling short 10 mm strokes with precision, this stainless steel round-body mini cylinder features needle-adjustable air cushions at both ends to decelerate loads smoothly. As a double-acting actuator, it generates 100.5 N of push force and 86.4 N of pull force at 0.5 MPa. The 16 mm bore uses an M5×0.8 port and a 6 mm piston rod with an M6x1.0 male thread. Its stainless construction resists mild corrosion, and the CM round rear cover provides a compact mounting footprint.
Designed to the ISO 6432 mounting interface for Ø16 bores, it drops directly into standard mini-cylinder brackets and clevises. For vertical applications, the 100.5 N push force yields a safe working load of roughly 60 N, meaning it lifts about 5.1 kg with a 2:1 safety margin. Note this specific SKU lacks the -S magnet, so it cannot accept CMSG, DMSG, or EMSG position switches.
Airtac MIC Cushioned Mini Cylinder MIC16X10CM Technical Specifications
| Model | Airtac MIC Cushioned Mini Cylinder MIC16X10CM |
|---|---|
| Series | MIC ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Double acting + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MIC Cushioned Mini Cylinder MIC16X10CM
| MIC | ISO 6432 round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MIC Cushioned Mini Cylinder MIC16X10CM Is Used
Small Part Ejection
Rapidly pushes lightweight plastic parts out of a molding area, using the adjustable cushion to stop the 10 mm stroke instantly without bouncing the delicate components.
Clamp Actuation
Secures small electronic housings during ultrasonic welding, applying 100.5 N of clamping force while the stainless body withstands occasional coolant splashes.
Gate Diverting
Pivots a tiny flow gate to redirect small fasteners down a chute, benefiting from the ISO 6432 mounting dimensions to fit into tight existing machinery brackets.
Is the Airtac MIC Cushioned Mini Cylinder MIC16X10CM the Right Cylinder?
When sizing this 16 mm bore, stepping down is not an option for cushioned models, as the smaller Ø8, Ø10, and Ø12 bores are bumper-only variants. If you need more force, the next size up is the Ø20 bore, which provides 157 N of push at 0.5 MPa compared to the 100.5 N offered here. The adjustable air cushion is essential if you are running near the 800 mm/s maximum speed or moving a heavy mass, allowing you to dial out end-of-stroke shock.
Because this is a plain double-acting cylinder, it will not hold a load if air pressure drops or the valve is centered, as the piston will drift. For vertical lifting or suspended loads, install an external rod lock or a pilot-operated check valve. Furthermore, since this SKU has no internal magnet, you must select an -S variant if your application requires magnetic sensing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MIC Cushioned Mini Cylinder MIC16X10CM FAQ
This 16 mm bore double-acting cylinder uses an M5×0.8 port. At 0.5 MPa it provides 100.5 N of push force and 86.4 N of pull force. At 0.7 MPa the push is 140.7 N and pull is 120.9 N. The theoretical maximum force is 20.5 kgf at 1.0 MPa.
No, this specific SKU does not include an internal magnet, so it cannot accept CMSG, DMSG, or EMSG switches. You must purchase the -S variant for position sensing. The adjustable air cushion at both ends only decelerates the load near the stroke end and does not lock or hold the piston in place.
