Airtac MIC Cushioned Mini Cylinder MIC16X135SU
The AirTAC Airtac MIC Cushioned Mini Cylinder MIC16X135SU is a genuine double acting + cushion round-body mini air cylinder with a Ø16mm bore and 135mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ16 mm
- Stroke135 mm
- Port sizeM5×0.8
- Acting typeDouble acting + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MIC Cushioned Mini Cylinder MIC16X135SU
Designed for light-duty actuation, this double-acting stainless steel round-body mini cylinder absorbs high-speed impact using a variable air cushion at both ends. The Ø16 bore conforms to the ISO 6432 mounting interface, dropping directly into standard mini brackets and clevises. A built-in piston magnet enables position sensing, and the U-style rear cover provides a 90-degree mounting orientation with an M5×0.8 port.
Generating 100.5 N of push force at 0.5 MPa, it provides a safe working load of about 60 N. In a vertical lift setup with a 2:1 safety margin, it lifts approximately 5.1 kg. The riveted stainless barrel and rod resist mild corrosion and washdown environments, offering superior durability compared to fixed-bumper alternatives.
Airtac MIC Cushioned Mini Cylinder MIC16X135SU Technical Specifications
| Model | Airtac MIC Cushioned Mini Cylinder MIC16X135SU |
|---|---|
| Series | MIC ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 135 mm |
| Acting type | Double acting + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MIC Cushioned Mini Cylinder MIC16X135SU
| MIC | ISO 6432 round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×135 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MIC Cushioned Mini Cylinder MIC16X135SU Is Used
Small Parts Ejection
Pushes lightweight plastic or aluminum components out of a machining fixture at high speed, using the adjustable cushion to prevent the rod from slamming against the end cap.
Package Diverting
Actuates a routing gate on a packaging line, handling loads safely within its 60 N working limit while the stainless build withstands occasional washdowns.
Lab Sample Sorting
Moves delicate test tubes or vials between stations, where the needle-tuned deceleration protects fragile glass from sudden impact at the 135 mm stroke end.
Is the Airtac MIC Cushioned Mini Cylinder MIC16X135SU the Right Cylinder?
For applications needing less force, the smaller bore MI series relies on a fixed rubber bumper rather than an adjustable cushion, making this MIC variant the better choice when controlling end-of-stroke shock is critical. If your project requires more power, stepping up to the Ø20 bore increases the 0.5 MPa push force to 157 N. The needle-set cushion shines in high-speed operations between 30 and 800 mm/s, allowing you to tune the deceleration profile precisely.
Because this is a standard double-acting cylinder, it will drift and cannot hold a load if air pressure drops or the valve is centered—the cushion only decelerates the piston near the stroke end, acting strictly as a shock absorber rather than a brake. To maintain position during air loss, install an external rod lock or a pilot-operated check valve. The -S suffix confirms the magnet is present for CMSG, DMSG, or EMSG switches.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MIC Cushioned Mini Cylinder MIC16X135SU FAQ
This double-acting cylinder features an M5×0.8 port and an M6x1.0 male rod thread. It generates 100.5 N push and 86.4 N pull at 0.5 MPa, 140.7 N push and 120.9 N pull at 0.7 MPa, with a theoretical maximum force of 20.5 kgf at 1.0 MPa.
The -S suffix means it has a built-in magnet for CMSG, DMSG, or EMSG switches. It cannot hold a vertical load on air loss—the piston will drift, as the adjustable air cushion only decelerates near the stroke end and does not act as a brake. Use a pilot check valve for holding.
