Airtac 2KL Solenoid Valve 2KL03006EI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03006EI Solenoid Valve Technical Details
- Model: 2KL03006EI
- Type: 5/3-way double solenoid (closed center)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8
- Response time: ≤20ms (excitation), ≤30ms (de-excitation)
- Weight: 680g ±2% (excluding connectors)
- Dimensions: 105mm(L) × 54mm(W) × 63mm(H)
- Body material: Die-cast aluminum alloy (anodized surface)
- Seal material: HNBR rubber (FDA compliant option available)
- Temperature range: -10℃ to 80℃ (with dry air)
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual manual override and position sensing capability. Features anti-vibration design with copper-free aluminum construction, optimized for precision pneumatic systems requiring mid-stroke positioning. Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 3.4.2) with ≤0.1mg/m³ oil content.
- Robotic arm end-effector control systems
- Plastic injection molding machine clamp mechanisms
- Automated assembly line positioning devices
- Semiconductor wafer handling equipment
- Textile machinery tension control systems
- Food processing pneumatic actuators (with FDA seals)
Installation requirements:
Mount with M5 screws (torque ≤1.2N·m). Maintain ambient temperature
below 60℃ with 85% RH max. Allow 15mm clearance for heat dissipation.
Use locknuts (included) for vibration-prone environments.
Critical note:
Requires 2-second minimum power-on delay after installation.
Never energize coils without air pressure. Compatible with
ISO VG32 turbine oil lubrication (1 drop/m³ air recommended).
| Property | Property Value |
|---|---|
| sku | 2KL03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
