Airtac 2KL Solenoid Valve 2KL03006FI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03006FI Solenoid Valve Technical Details
- Model: 2KL03006FI
- Type: 5/2-way monostable (single solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V
- Flow capacity: 850 l/min (ANR)
- Weight: 380g ±5%
- Dimensions: 63mm(L) × 47mm(W) × 82mm(H)
- Seal material: Heat-resistant FKM fluorocarbon
- Temperature range: -10℃ to 90℃ (with FKM seals)
- Power consumption: 2.5W (DC), 5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with manual override, featuring a metal piston design for enhanced durability in high-cycle applications. The dual-coil suppression circuit minimizes electrical interference. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.2 air quality standards.
- Semiconductor wafer handling robotics
- Plastic injection molding machine actuators
- Automotive assembly line clamping systems
- Food processing pneumatic circuits (FDA-compliant variants available)
- High-speed packaging equipment (up to 10Hz cycling)
Installation guidelines:
Mount with M5 screws (max torque 2.5N·m). For horizontal installation,
use exhaust silencers (AS-12 series recommended). Lubricate pivot points
every 2,000 operating hours with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2KL03006FI |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
