Airtac 2KL Solenoid Valve 2KL03008CI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03008CI Solenoid Valve Specifications
- Model: 2KL03008CI
- Type: 5/3-way double solenoid, center closed position
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±3% (with connector)
- Dimensions: 108mm(L) × 42mm(W) × 68mm(H)
- Flow coefficient (Cv): 1.6
- Seal material: Heat-resistant NBR (Nitrile) - upgraded formula
- Temperature range: -10℃ to 80℃ (extended range with optional seals)
- Power consumption: 3.6W (DC), 4.5VA (AC)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dustproof & temporary immersion protection)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with precision magnetic circuit design, featuring dual manual overrides and LED status indicators. The 5/3-way configuration allows complex cylinder control sequences. Enhanced corrosion resistance with nickel-plated brass body and aviation-grade aluminum coil housing. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with mid-stroke positioning
- Bottle filling/palletizing systems requiring intermediate stops
- Test bench pressure cycling equipment
Installation guidelines:
Mount horizontally with coil upright. Allow 20mm clearance below for exhaust flow.
Use anti-vibration washers in high-shock environments. Lubricate every 5 million cycles
using ISO VG32 turbine oil. Avoid rapid pressure fluctuations >0.3 MPa/sec.
| Property | Property Value |
|---|---|
| sku | 2KL03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC 110V |
