Airtac 2KL Solenoid Valve 2KL05010E
$74.41
Regular price
$81.91
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2KL05010E
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Direct-acting normally open 2-way, 2-position solenoid valve featuring rapid switching and high sensitivity;
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤1.2N·m).
Maintain ambient humidity below 85% RH. Lubricate sliding parts with ISO VG32
turbine oil if operated over 100,000 cycles/month.
Critical note:
Always install downstream pressure regulator. Coil replacement requires matching
voltage specification (±10% tolerance). Avoid axial side-load on exhaust ports.
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL05010E 5/2-Way Solenoid Valve Technical Details
- Model: 2KL05010E (Double coil latching type)
- Function: 5-port 2-position (5/2-way)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V±10%, DC24V±10%, AC110V±10%(50/60Hz), AC220V±10%(50/60Hz)
- Max flow rate: 750 L/min (ANR)
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Response time: ≤15ms (at 20℃, rated voltage)
- Protection class: IP65 (Dust-tight & water jet resistant)
- Port thread depth: 12mm (minimum engagement)
- Weight: 0.48 kg ±3%
- Dimensions: 98mm(L) × 46mm(W) × 68.5mm(H)
- Manual override: Optional (side-mounted push button)
High-flow bistable solenoid valve with energy-saving latching design, maintaining position without continuous power. Features brass body with hard anodized aluminum core for corrosion resistance. Requires 40μm filtered compressed air with oil mist (ISO 8573-1 class 4).
Industrial Applications:
- Pneumatic cylinder position control systems
- Automated assembly line actuators
- Textile machinery clamping devices
- Plastic injection molding machines
- Packaging equipment with dual-action cylinders
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (torque ≤1.2N·m).
Maintain ambient humidity below 85% RH. Lubricate sliding parts with ISO VG32
turbine oil if operated over 100,000 cycles/month.
Critical note:
Always install downstream pressure regulator. Coil replacement requires matching
voltage specification (±10% tolerance). Avoid axial side-load on exhaust ports.
| Property | Property Value |
|---|---|
| sku | 2KL05010E |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
