Airtac 4HV Manual Rotary Valve 4HV21008S
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV21008S Manual Rotary Valve Specifications
- Model: 4HV21008S
- Type: 3/2-way manual rotary valve (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Manual override: 90° rotary operation with positive detent
- Weight: ~220g (including fittings)
- Dimensions: 52mm(L) × 32mm(W) × 68mm(H)
- Body material: Anodized aluminum alloy
- Seal material: High-grade NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Flow rate: 750 L/min (ANR)
- Response time: Instantaneous mechanical actuation
- Protection rating: IP54 (dust and splash resistant)
Robust manual override valve designed for emergency control and system debugging in pneumatic circuits. Features tactile position feedback and corrosion-resistant construction. The ergonomic rotary knob allows single-finger operation with clear ON/OFF indication. Compatible with ISO 15407-1 standards.
- Emergency stop override in production line pneumatics
- Maintenance bypass in automated assembly systems
- Manual mode switching for hydraulic test benches
- Process control override in semiconductor manufacturing
- Safety circuit isolation in cleanroom equipment
Installation note:
Mount in accessible locations for manual access. Apply thread sealant on port connections.
Maximum torque for knob rotation: 0.5 N·m. Lubricate pivot point annually with silicone grease.
| Property | Property Value |
|---|---|
| sku | 4HV21008S |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
