Airtac 4HV Manual Rotary Valve 4HV230-06
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV230-06 Manual Rotary Valve Technical Details
- Model: 4HV230-06
- Type: 3-position (L-type) detent manual valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.7 MPa
- Flow capacity: 650 NL/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Spindle material: Stainless steel SUS304
- Seal material: HNBR (heat-resistant variant)
- Operating temperature: -20℃ to 80℃
- Weight: 320g ±5g
- Dimensions: 62mm(L) × 38mm(W) × 33mm(H)
- Port thread depth: 10mm (minimum engagement)
- Torque requirement: ≤0.5 N·m
- Position indicator: Colored rotary knob (green/black)
- Mounting options: Direct panel mount or bracket installation
Robust manual override valve with positive position locking, featuring a wear-resistant ceramic spindle core for smooth rotation. The ergonomic knurled knob provides tactile feedback during operation. Designed for systems requiring manual intervention without pneumatic pressure. Includes built-in dust shield for industrial environments.
- Emergency stop/purge circuits in production lines
- Manual mode override in automated assembly systems
- Pressure regulation in pneumatic testing benches
- Maintenance bypass control for hydraulic power units
- Educational training equipment for fluid power systems
Installation tip:
Apply thread sealant only on male ports (not on first two threads).
For vertical mounting, orient exhaust port downward to prevent debris accumulation.
Lubricate spindle quarterly with silicone-based grease (ISO VG 10).
| Property | Property Value |
|---|---|
| sku | 4HV230-06 |
| Position | 4-way, 3-position |
| Port Size | PT1/8 |
