Airtac 4HV Manual Rotary Valve 4HV230-08
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV230-08 Manual Rotary Valve Technical Details
- Model: 4HV230-08
- Type: 4-way/3-position manual rotary valve (closed center)
- Port configuration: P (pressure), A, B, R (exhaust)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Operating temperature: -5℃ to 80℃
- Valve body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Actuation torque: ≤1.5 N·m
- Weight: 350g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 50mm(H)
- Mounting: Panel mount with M5 threaded holes
- Position indication: Mechanical pointer with engraved markings
- Leakage: <0.1 mL/min under rated pressure
Robust manual override valve with precision-machined brass core and ergonomic rotary knob. Features a spring-centered mechanism with positive detent positions (A/B/neutral). The corrosion-resistant design includes IP54-rated dust/water protection, making it suitable for harsh environments. Requires ISO 8573-1:2010 Class 3 compressed air quality.
- Emergency override in automated production lines
- Manual control of pneumatic cylinders in assembly jigs
- Pressure regulation in plastic injection molding machines
- Safety isolation during equipment maintenance
- Educational training systems for pneumatic circuits
Operation guidance:
Rotate knob 90° between positions with firm, steady pressure.
Avoid sudden impacts - engage detents fully to prevent mid-position leakage.
Lubricate shaft quarterly with ISO VG32 hydraulic oil.
Critical note:
Do not exceed 1.0 MPa operating pressure.
Always depressurize system before changing positions.
Install downstream filter (5μm) when used with pneumatic actuators.
| Property | Property Value |
|---|---|
| sku | 4HV230-08 |
| Position | 4-way, 3-position |
| Port Size | PT1/4 |
