Airtac 4HV Manual Rotary Valve 4HV310-08
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV310-08 Manual Rotary Valve Specifications
- Model: 4HV310-08
- Type: 3-position (Lever-operated detent type)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 1,200 NL/min (ANR)
- Actuation torque: ≤1.5 N·m
- Body material: Die-cast aluminum alloy (surface anodized)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 80℃
- Weight: 0.85 kg ±5%
- Dimensions: 98mm(L) × 62mm(W) × 85mm(H)
- Port thread depth: 12mm (both ends)
- Leakage rate: ≤20 cm³/min (at 0.5 MPa)
- Protection rating: IP54 (dust-resistant, splash-proof)
Heavy-duty manual directional control valve with positive center position lock, featuring wear-resistant chromium-plated spool and ergonomic lever design. The dual-seal structure prevents cross-port leakage even under vibration. Compatible with ISO 15407-1 standard mounting interfaces.
- Emergency shut-off in pneumatic conveyor systems
- Manual override for automated production lines
- Air circuit switching in construction machinery
- Pressure regulation in hydraulic test benches
- Dusty environment operations (e.g., foundries, cement plants)
Installation note:
Mount in accessible locations with lever movement clearance ≥120°.
Apply thread sealant (PTFE tape recommended) on port threads.
Perform monthly lubrication of pivot points using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | 4HV310-08 |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
