Airtac 4HV Manual Rotary Valve 4HV310-10
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV310-10 Manual Rotary Valve Technical Details
- Model: 4HV310-10
- Type: 3-position (Lever Operated) Detent Type
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 1,200 Nl/min (ANR)
- Weight: ~220g (excluding handle)
- Dimensions: 55mm(L) × 35mm(W) × 70mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃
- Operating torque: ≤1.5 N·m
- Port thread depth: 12mm
- Position indication: Mechanical position marker
- Mounting options: Panel mount with M5 screws
Manual override valve with positive locking mechanism for precise flow control in pneumatic systems. Features zero-leakage design with 90° lever rotation between positions. The chrome-plated shaft and wear-resistant seals ensure 500,000+ cycle durability. Compatible with ISO 15407-1 standards.
- Emergency override in automated production lines
- Manual flow regulation in hydraulic test benches
- Position locking for maintenance safety in press machines
- Educational pneumatic training equipment
- Mobile machinery requiring manual override capability
Operation guidance:
Rotate lever clockwise for flow path A→P→B, counter-clockwise for B→P→A.
Apply firm pressure until audible "click" confirms position engagement.
Lubricate pivot point every 6 months with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | 4HV310-10 |
| Position | 4-way 2-position |
| Port Size | PT3/8 |
