Airtac 4HV Manual Rotary Valve 4HV31008L
$40.70
Regular price
$48.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4HV31008L
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Lightweight directional switching rotation with excellent tactile feedback and precise positioning;
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
Operation guidance:
Always depressurize system before position change. Lubricate spindle quarterly
with ISO VG32 hydraulic oil. Arrow markings indicate flow direction - align with
port labels during installation.
Caution:
Not suitable for vacuum applications. Maximum 500,000 cycle life when used within
specified pressure range. Replace O-rings annually in continuous operation.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV31008L Manual Rotary Valve Specifications
- Model: 4HV31008L
- Type: 3-position manual rotary valve (Lockable)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Valve body material: Aluminum alloy (anodized finish)
- Seal material: HNBR rubber (-20℃ to 150℃)
- Operating temperature: -20℃ to 80℃ (non-freezing)
- Weight: 0.38 kg (0.84 lbs)
- Dimensions: 68mm(L) × 42mm(W) × 72mm(H)
- Port thread depth: 10mm (minimum engagement)
- Rotational torque: ≤1.5 N·m
- Position indicator: Colored cam mechanism
Industrial-grade manual override valve with positive locking mechanism, featuring 3-position control (A/B/Exhaust). The dual-bearing rotary structure ensures smooth operation under pressure fluctuations. Integrated dust shield prevents particulate ingress in harsh environments.
Typical Applications:
- Emergency override in automated production lines
- Pneumatic system maintenance bypass
- Material handling equipment manual control
- Test bench pressure regulation
- Robotic arm pneumatic circuit isolation
Operation guidance:
Always depressurize system before position change. Lubricate spindle quarterly
with ISO VG32 hydraulic oil. Arrow markings indicate flow direction - align with
port labels during installation.
Caution:
Not suitable for vacuum applications. Maximum 500,000 cycle life when used within
specified pressure range. Replace O-rings annually in continuous operation.
| Property | Property Value |
|---|---|
| sku | 4HV31008L |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
