Airtac 4HV Manual Rotary Valve 4HV31008SL
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV31008SL Manual Rotary Valve Technical Details
- Model: 4HV31008SL
- Type: 3-position (L-type) detent manual rotary valve
- Port configuration: 4 ports (P, A, B, T) / 3 positions
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 850 L/min (ANR)
- Valve body material: Anodized aluminum alloy
- Spindle material: Stainless steel SUS303
- Seals: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Operating temperature: -10℃ to 120℃ (14℉ to 248℉)
- Weight: 320g ±5% (including accessories)
- Dimensions: 58mm(L) × 34mm(W) × 52mm(H)
- Mounting: Panel mount with M5 mounting holes
- Torque requirement: ≤1.5 N·m (manual operation)
- Lubrication: Pre-lubricated (maintenance-free for 2 million cycles)
Industrial-grade manual override valve with precision machining and tactile position feedback. Features 45° rotational stroke with positive detent mechanism for precise flow path selection. The chrome-plated spindle and wear-resistant seals ensure smooth operation under high-cycle conditions. Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency override in automated production lines
- Process control in plastic injection molding machines
- Manual mode switching for CNC tool changers
- Safety bypass in chemical dosing systems
- Position selection in semiconductor handling equipment
Installation note:
Apply thread sealant (PTFE tape recommended) on port threads.
Ensure valve position indicators face the operator.
Maximum allowable side load on spindle: 30N.
Perform monthly visual inspection for metal particles in dirty environments.
| Property | Property Value |
|---|---|
| sku | 4HV31008SL |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
