Airtac 4HV Manual Rotary Valve 4HV31010S
$33.72
Regular price
$41.22
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4HV31010S
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Lightweight directional switching rotation with excellent tactile feedback and precise positioning;
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
Installation note:
Apply thread sealant to port connections (PTFE tape not recommended).
Lubricate pivot point with ISO VG32 hydraulic oil quarterly.
Maximum lateral force on lever: 50N.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV31010S Manual Rotary Valve Specifications
- Model: 4HV31010S
- Type: 3-position (Lever Operated) / 4-way closed center
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 750 L/min (Cv=1.3)
- Operating temperature: -5℃ to 80℃ (23°F to 176°F)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Actuation torque: ≤1.5 N·m
- Weight: 0.48 kg (1.06 lbs)
- Dimensions: 68mm(W) × 68mm(H) × 82mm(L)
- Port thread depth: 12mm
- Leakage: <30 mL/min under 0.5 MPa
- Protection rating: IP54 (dust protected, water splashed)
Manual override valve with positive detent positions and zero-point locking mechanism. Features wear-resistant pivot bearings and anti-corrosion surface treatment. Designed for precise directional control in hazardous environments where electrical components are prohibited.
Typical Applications:
- Emergency shutdown systems in chemical plants
- Hydraulic press manual override control
- Mining equipment pneumatic circuits
- Food processing machinery (oil/fat-resistant seals)
- Test bench pressure regulation systems
Installation note:
Apply thread sealant to port connections (PTFE tape not recommended).
Lubricate pivot point with ISO VG32 hydraulic oil quarterly.
Maximum lateral force on lever: 50N.
| Property | Property Value |
|---|---|
| sku | 4HV31010S |
| Position | 4-way 2-position |
| Port Size | PT3/8 |
