Airtac 4HV Manual Rotary Valve 4HV330-08
$31.24
Regular price
$38.74
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4HV330-08
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Lightweight directional switching rotation with excellent tactile feedback and precise positioning;
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
Important: Always depressurize system before manual operation.
Not suitable for continuous rotary motion applications - maximum 300
position changes/hour recommended.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV330-08 Manual Rotary Valve Technical Details
- Model: 4HV330-08
- Type: 3-position (Lever Operated) Detent Type
- Port configuration: 3/4-way (5 ports)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: Nitrile Butadiene Rubber (NBR)
- Body material: Anodized aluminum alloy
- Manual operation torque: ≤1.5 N·m
- Weight: 300g ±5% (0.66 lbs)
- Dimensions: 62mm(W) × 48mm(H) × 88mm(L)
- Mounting options: Panel mount with M5 screws
- Position indication: Colored position markers (Green/Red/Yellow)
Robust manual override valve with positive detent mechanism for precise position control. Features dual O-ring sealing for leak-free operation and ergonomic lever design requiring ≤2.5kg operating force. Compatible with ISO 15407-1 standards for industrial environments.
Common Use Cases:
- Emergency override in automated production lines
- Pneumatic system maintenance bypass
- Manual mode switching in material handling systems
- Educational pneumatic training setups
- Mobile equipment hydraulic controls
Installation Guidelines:
- Mount in accessible locations with minimum 50mm clearance for lever operation
- Use thread sealant on port connections (PTFE tape not recommended)
- Lubricate with ISO VG32 hydraulic oil if used in high-cycle applications
- Maximum allowable side load on lever: 15N
Important: Always depressurize system before manual operation.
Not suitable for continuous rotary motion applications - maximum 300
position changes/hour recommended.
| Property | Property Value |
|---|---|
| sku | 4HV330-08 |
| Position | 4-way, 3-position |
| Port Size | PT1/4 |
