Airtac 4HV Manual Rotary Valve 4HV330-10
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV330-10 Manual Rotary Valve Specifications
- Model: 4HV330-10
- Type: 3-position (L-type flow path) manual rotary valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Manual torque: ≤1.5 N·m
- Weight: 600g ±5%
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Nitrile rubber (NBR) with PTFE backup rings
- Port thread depth: 12mm (minimum engagement 9mm)
- Leakage rate: ≤3 bubbles/min (ISO 6952 test standard)
- Protection rating: IP65 (dust-tight & low-pressure water jet resistant)
Mechanical locking rotary valve with positive position feedback, featuring a corrosion-resistant aluminum body and precision-machined brass core. The 90° rotation mechanism provides tactile positioning with dust-proof O-ring seals. Designed for manual override applications requiring physical position confirmation.
- Emergency shutdown systems in pneumatic circuits
- Manual mode switching in automated production lines
- Maintenance bypass control for hydraulic test benches
- Air flow direction control in semiconductor handling equipment
- Safety isolation in chemical process piping
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on port threads.
Avoid side-loading during operation - ensure free rotation arc of 100° minimum.
Lubricate spindle quarterly with silicone-free grease (ISO VG32 equivalent).
| Property | Property Value |
|---|---|
| sku | 4HV330-10 |
| Position | 4-way, 3-position |
| Port Size | PT3/8 |
