Airtac 4HV Manual Rotary Valve 4HV410-20
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV410-20 Manual Rotary Valve Specifications
- Model: 4HV410-20
- Type: 4-port 3-position manual rotary valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile rubber)
- Body material: Anodized aluminum alloy
- Mounting style: Panel mount with M5 screw holes
- Rotation torque: ≤0.5 N·m
- Protection rating: IP54 (dust and splash resistant)
- Weight: 450g (0.99 lbs)
- Dimensions: 50mm(W) × 50mm(H) × 60mm(D)
Robust manual control valve featuring a positive detent mechanism for precise position selection. The 90° rotary handle offers tactile feedback with clear center/end position indicators. Designed for systems requiring manual override or non-electrical flow control, with wear-resistant bushings for extended cycle life (≥500,000 rotations). Compatible with ISO 8573-1:2010 Class 3 compressed air.
- Production line emergency shut-off systems
- Pneumatic training equipment and educational kits
- Material handling system diverters
- Food processing machinery manual controls
- Mobile hydraulic/pneumatic hybrid systems
- Medical equipment maintenance bypass
Installation note:
Apply silicone-free lubricant to shaft bushing during assembly.
Ensure port alignment matches handle position markings.
Maximum recommended mounting torque: 1.2 N·m (use included nylon washer).
| Property | Property Value |
|---|---|
| sku | 4HV410-20 |
| Position | 4-way 2-position |
| Port Size | BSPT 3/4 |
