Airtac 4HV Manual Rotary Valve 4HV430-15
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4HV430-15
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Lightweight directional switching rotation with excellent tactile feedback and precise positioning;
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
Operation guidance:
Rotate knob clockwise with 2-3 N·m torque. Lubricate shaft quarterly with ISO VG32 hydraulic oil.
Avoid side-loading during rotation. For vertical installation, ensure exhaust port faces downward.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV430-15 Manual Rotary Valve Specifications
- Model: 4HV430-15
- Type: 3-position (L-type) manual rotary valve
- Port configuration: 4 ports (P, A, B, R) with 3 positions
- Port size: G1/8 (BSPP thread standard)
- Operating pressure: 0.05–0.8 MPa
- Max flow rate: 600 NL/min (at 0.5 MPa)
- Valve body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Operating temperature: -20℃ to 80℃
- Manual rotation angle: 90° per position
- Weight: 320g ±5g
- Dimensions: 54mm(L) × 54mm(W) × 54mm(H)
- Mounting options: Panel mount with M5 screw holes (4x)
- Leakage rate: ≤0.3 NL/min (under 0.5 MPa)
- Durability: ≥500,000 cycles
Robust manual override valve with precision-machined brass core and tactile position feedback. Features triple sealing structure for leak-free operation and ergonomic knurled knob for gloved-hand operation. Compatible with ISO 15407-1 standards.
Typical Applications:
- Emergency override in automated production lines
- Pneumatic circuit configuration during machine maintenance
- Manual mode switching in semiconductor handling equipment
- Position control in material handling systems
- Prototype pneumatic system debugging
Operation guidance:
Rotate knob clockwise with 2-3 N·m torque. Lubricate shaft quarterly with ISO VG32 hydraulic oil.
Avoid side-loading during rotation. For vertical installation, ensure exhaust port faces downward.
| Property | Property Value |
|---|---|
| sku | 4HV430-15 |
| Position | 4-way, 3-position |
| Port Size | PT 1/2 |
