Airtac 4HV Manual Rotary Valve 4HV430-20-S-L
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV430-20-S-L Manual Rotary Valve Technical Details
- Full model designation: 4HV430-20-S-L
- Valve type: 4-way/3-position manual rotary valve
- Port configuration: 4 ports (P, A, B, T) with 3 positions
- Port thread size: PT1/4 (BSPP standard)
- Operating pressure range: 0.1–0.8 MPa (14.5–116 PSI)
- Maximum flow rate: 750 L/min (Cv=1.3)
- Manual operation torque: ≤1.5 N·m
- Seal material: High-grade NBR (Nitrile) with glass fiber reinforcement
- Body material: Anodized aluminum alloy (hard coating 25μm)
- Temperature tolerance: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 500g ±5% (including mounting hardware)
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H)
- Mounting pattern: ISO 15407-1 compliant
- Vibration resistance: ≤50 m/s² (10-1500 Hz)
- Position indication: Tactile detent with visual arrow marking
Industrial-grade manual override valve featuring positive center position locking and smooth 90° rotation action. The hardened spindle with triple O-ring seals ensures leak-free performance in high-cycle applications. Integrated dust shield prevents particulate ingress in harsh environments.
- Emergency override in automated production lines
- Manual control of clamping fixtures in CNC machining centers
- Pneumatic circuit isolation during maintenance operations
- Material handling systems requiring position hold function
- Test bench pressure regulation setups
Operational guidance:
Apply silicone-free lubricant (ISO VG32 grade) quarterly on rotating shaft.
For horizontal mounting, ensure exhaust port orientation faces downward
to prevent condensate accumulation. Maximum 200N lateral force permitted
during handle operation.
| Property | Property Value |
|---|---|
| sku | 4HV430-20-S-L |
| Position | 4-way, 3-position |
| Port Size | BSPT 3/4 |
