Description
AIRTAC 4V Series Solenoid Valve Coils
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
Installation note:
Use 0.5-0.8Nm torque for terminal screws. Maintain minimum 3mm clearance
from heat sources. For vertical mounting, position cable outlet downward
to prevent moisture ingress.
Requires 24VDC regulated power supply with ≤5% ripple.
Do NOT use with AC voltage or PWM controllers.
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-016-2A Coil Terminal Specifications
- Model: 4V110-016-2A
- Type: DIN-standard solenoid coil (24VDC)
- Voltage: 24V DC ±10%
- Power consumption: 2.5W (1.8W during hold)
- Insulation class: Class F (155°C)
- Protection rating: IP67 (dust/water resistant)
- Terminal type: DIN43650 Form A connector
- Wire length: 300mm ±20mm
- Lead wire specification: 22 AWG PVC insulated (black/blue)
- Operating temperature: -20℃ to 120℃ (ambient)
- Duty cycle: 100% ED (continuous operation capable)
- Coil inductance: 450mH ±10%
- Weight: 180g ±5g
- Dimensions: 40mm(L) × 30mm(W) × 55mm(H)
- Certification: CE, RoHS compliant
High-performance solenoid coil with UL-certified copper windings and overcurrent protection. Features shock-resistant epoxy encapsulation and gold-plated contacts for reliable connectivity in high-vibration environments. Compatible with 4V1 series valves.
Typical Applications:
- Automated assembly line valve clusters
- Food processing pneumatic systems
- CNC machine tool pneumatic controls
- Railway braking system interfaces
- Plastic injection molding machines
Installation note:
Use 0.5-0.8Nm torque for terminal screws. Maintain minimum 3mm clearance
from heat sources. For vertical mounting, position cable outlet downward
to prevent moisture ingress.
Requires 24VDC regulated power supply with ≤5% ripple.
Do NOT use with AC voltage or PWM controllers.
| Property | Property Value |
|---|---|
| sku | 4V110-016-2A |
