Airtac 4V Coil Terminal 4V110-016-7A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-016-7A Coil Terminal Technical Specifications
- Model: 4V110-016-7A
- Type: DIN-type plug connector for solenoid valves
- Compatible series: 4V2/4V3/4VH series solenoid valves
- Contact configuration: 2-pin (with LED indicator)
- Voltage rating: DC12V/24V ±10% (customizable for AC voltages)
- Current capacity: 1.5A continuous (2.5A surge)
- Insulation resistance: ≥100MΩ (500VDC megger test)
- Dielectric strength: 1500V AC for 1min
- Wire connection: 22-16 AWG crimp terminals
- Housing material: PA66+30%GF (UL94 V-0 rated)
- Contact material: Gold-plated brass
- Protection class: IP67 (mated)/IP40 (unmated)
- Operating temperature: -25℃ to +100℃
- Weight: 28g ±1g (excluding cable)
- Dimensions: 32mm(L) × 19mm(W) × 23mm(H)
High-density electromagnetic coil connector with integrated status LED, featuring military-grade vibration resistance (tested to 10-55Hz/1.5mm amplitude). The bayonet locking mechanism ensures secure connection in high-shock environments. Includes built-in surge protection diode for enhanced electrical stability.
- Automated assembly line valve manifolds
- Mobile hydraulic control systems
- Food processing equipment with frequent washdown
- Plastic injection molding machines
- High-cycle pneumatic sorting systems (≥5 million operations)
Wiring guidance:
Use 600V rated PVC insulated wires. Maintain minimum bending radius of 15mm.
For daisy-chaining multiple coils, verify total current draw doesn't exceed power supply capacity.
- Optimal with 4V210-08/4V230-15 valves
- Requires matching valve socket: AS-0221-2P
- Not compatible with 4V1 series compact valves
| Property | Property Value |
|---|---|
| sku | 4V110-016-7A |
