Airtac 4V Coil Terminal 4V210-016-7A

$11.59 $19.09
sold in last hours
customers are viewing this product
Ask A Question

SKU:
In stock
SKU:
4V210-016-7A
Product type:
Control Components>>Solenoid Valve>>Ordinary Coils
Tags:
,
Collections:
Airtac Control Components, Airtac Ordinary Coils, Airtac Solenoid Valve

DELIVERY
Estimated delivery between and
Guarantee Safe Checkout
Airtac Online Distributors/Supplier Store
Description
AIRTAC 4V Series Solenoid Valve Coils
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V

Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.

AirTAC 4V210-016-7A Coil Terminal Specifications

  • Model: 4V210-016-7A
  • Type: DIN-type plug-in coil (24VDC)
  • Voltage: DC24V ±10%
  • Power consumption: 2.8W (0.12A @24VDC)
  • Operating pressure: 0~0.8 MPa
  • Port size: PT1/4 (G1/4 optional)
  • Core tube material: Stainless steel SUS304
  • Insulation class: Class F (155℃)
  • Temperature range: -5℃ to 70℃ (no freezing)
  • Protection rating: IP65 (dustproof & water jet resistant)
  • Lead wire length: 300mm ±10% (UL2651 22AWG)
  • Weight: 215g ±5g
  • Dimensions: 54mm(L) × 36mm(W) × 42mm(H)
  • Connector type: 2-pin rectangular plug (IEC standard)
  • Dielectric strength: AC1500V 1min (coil to frame)

High-performance solenoid coil with overcurrent protection design, featuring anti-vibration terminals and epoxy resin encapsulation. The optimized magnetic circuit ensures stable operation under voltage fluctuations (18-30VDC). Compatible with 4V210 series valves.

Typical Applications:
  • Plastic injection molding machine valve clusters
  • Automated assembly line pneumatic actuators
  • Semiconductor manufacturing equipment
  • CNC machine tool pneumatic systems
  • Food packaging machinery with frequent valve switching
Installation notes:
  1. Ensure coil voltage matches power supply (±10% tolerance)
  2. Use torque 0.5-0.6N·m when mounting to valve
  3. Keep 50mm clearance from high-temperature components (>80℃)
  4. Apply silicone grease (ASG-30) on O-ring before installation


Property Property Value
sku 4V210-016-7A
