Airtac 6V-F Base 6V0500M1F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V0500M1F Technical Details
- Model: 6V0500M1F (6V-F Series)
- Material: Anodized aluminum alloy (black oxidation)
- Mounting Type: ISO 15407-1 compliant sub-base
- Compatible Valves: 6V1/4"~6V1" series solenoid valves
- Port Configuration: 5 ports (1 inlet, 2 outlets, 2 exhausts)
- Thread Size: G1/8"~G1/2" (BSPP standard)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Surface Hardness: HV 120±10 (anodized layer)
- Weight: 320±10g
- Dimensions: 98mm(L) × 54mm(W) × 32mm(H)
- Seal Material: Oil-resistant NBR (replaceable)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Mounting Torque: 1.2-1.5 N·m (for M5 screws)
Modular base designed for multi-valve manifold systems, featuring integrated air passageways and staggered port alignment for compact piping layouts. The hardened anodized surface prevents galling during assembly and resists chemical corrosion. Includes built-in silencer pads and optional pressure gauge ports (requires drilling).
- Centralized control manifolds in beverage filling lines
- Modular pneumatic stations for CNC tool changers
- Multi-axis actuator control in automotive assembly robots
- Compressed air distribution in semiconductor handling equipment
Installation protocol:
Apply Loctite 542 thread sealant on port connections.
Use torque wrench for even pressure distribution during manifold stacking.
Maximum 8 valves per manifold without auxiliary support brackets.
