Airtac 6V-F Base 6V0500M4F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Mounting Base 6V0500M4F Technical Details
- Model Code: 6V0500M4F
- Series: 6V-F (Heavy-duty Modular Mounting System)
- Compatible Cylinder Bore: Ø50mm (Optimized for MY1B/MAL Series)
- Material: A6063-T5 Aluminum Alloy with Hard Anodized Surface (HV400+)
- Mounting Pattern: ISO 15552 Standard (DIN/VDMA 24562)
- Thread Specifications: 4×M4×0.7 Deep Thread Holes (8mm Depth)
- Surface Flatness: ≤0.05mm (Precision Ground Finish)
- Weight: 320g ±5g (Unpackaged)
- Dimensions: 72mm(L) × 50mm(W) × 18mm(H)
- Temperature Range: -20℃ to 150℃ (Static Operation)
- Vibration Resistance: 10-55Hz @ 1.5mm Amplitude
- Corrosion Protection: MIL-STD-810G Salt Spray Test Compliant
Modular mounting base engineered for high-moment applications in multi-axis pneumatic systems. Features precision-machined alignment grooves (+0/-0.015mm tolerance) and anti-loosening thread design. Includes integrated cable routing channels for clean installation. Compatible with both horizontal and vertical mounting configurations.
- Robotic welding fixture positioning systems
- High-cycle packaging machine gripper assemblies
- Semiconductor wafer handling vacuum chambers
- Automotive test bench clamping mechanisms
- Food processing conveyor alignment guides
Installation Protocol:
Use JIS B 1053 Class 8.8 fasteners with spring washers.
Apply 1.2-1.5N·m torque during assembly.
Perform concentricity check using 50mm gauge pin (max 0.1mm runout).
| Property | Property Value |
|---|---|
| sku | 6V0500M4F |
