Airtac 6V-F Base 6V0500M5F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V0500M5F Technical Details
- Model: 6V0500M5F
- Type: Modular pneumatic base bracket
- Material: Aluminum alloy (anodized surface treatment)
- Port size: M5 x 0.8 (ISO standard metric thread)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 850g ±2%
- Dimensions: 50mm(L) × 42mm(W) × 30mm(H)
- Mounting interface: 22mm slot spacing (ISO 15407-1 compliant)
- Compatible valves: 6V-F series solenoid valves (6V1/6V2/6V3)
- Protection rating: IP40 (dust protected)
- Surface hardness: HV 120-150
- Certifications: RoHS compliant, ISO 9001 manufacturing
Precision-engineered mounting base for modular valve systems, featuring dual-row port configuration for space-efficient manifold assemblies. The hardened anodized surface resists chemical corrosion and mechanical wear, while the integrated O-ring groove ensures leak-free connections. Designed for high-density valve arrangements in automated systems.
- Modular pneumatic control stations
- Multi-valve manifolds in packaging lines
- Robotic end-effector tooling systems
- Semiconductor manufacturing equipment
- Laboratory analytical instrument pneumatics
Installation note:
Use torque-controlled tightening (0.7-1.2N·m) for valve mounting screws.
Apply silicone-free lubricant to O-rings during assembly. Compatible with
ISO 15407-1 compliant manifold plates. Maximum stacking: 3 units vertically.
| Property | Property Value |
|---|---|
| sku | 6V0500M5F |
