Airtac 6V-F Base 6V0500M6F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V0500M6F Technical Details
- Model: 6V0500M6F
- Series: 6V-F Standard Base Bracket
- Material: Aluminum alloy (ADC12) with anodized surface treatment
- Port size: M6 (ISO 6149-1 metric thread)
- Mounting type: Through-hole with 4x M6 mounting bolts
- Operating pressure range: 0.05–0.9 MPa
- Temperature resistance: -20℃ to 80℃
- Surface hardness: ≥HV150
- Weight: 0.85 kg ±3%
- Dimensions: 50mm(L) × 50mm(W) × 50mm(H)
- Mounting hole spacing: 40mm × 40mm (square pattern)
- Bore compatibility: Designed for Ø32-50mm cylinders
- Seal material: NBR (Nitrile rubber)
- Corrosion resistance: 500hrs salt spray test passed
Heavy-duty mounting bracket engineered for stable cylinder fixation in high-vibration environments. Features precision-machined alignment grooves and universal mounting patterns compatible with multiple cylinder series. The anodized surface provides enhanced wear resistance against mechanical abrasion and chemical splashes.
- Pneumatic press machine bases
- Assembly line clamping fixtures
- Material handling robot end effectors
- Packaging machine vertical actuators
- Automotive welding jig installations
Installation protocol:
Use 8.8 grade M6 bolts with recommended torque of 4.5-5.5 N·m.
Apply thread-locking compound for permanent installations.
Ensure base surface flatness ≤0.1mm before mounting.
| Property | Property Value |
|---|---|
| sku | 6V0500M6F |
