Airtac 6V-F Base 6V0500M7F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Base Unit 6V0500M7F Technical Specifications
- Model: 6V0500M7F
- Series: 6V-F Modular Valve Base
- Material: Aluminum alloy (anodized surface treatment)
- Port size: PT1/4 (G1/4 equivalent)
- Port configuration: 5-port manifold base
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 L/min (ANR)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Mounting type: ISO 5599-1 standard compliant
- Weight: 650g ±2%
- Dimensions: 76mm(L) × 32mm(W) × 42mm(H)
- Port spacing: 30mm center-to-center
- Surface hardness: HV 120-150
- Corrosion resistance: 96hr salt spray test passed
Precision-engineered modular base for multi-valve manifold systems, featuring leak-proof design with integrated O-ring grooves. The staggered port layout minimizes pressure drop while maintaining compact dimensions. Compatible with all 6V series valves and available with optional silencer/flow control accessories.
- Centralized pneumatic control panels
- Automated assembly line actuator clusters
- Robotic tool changing systems
- Plastic injection molding machines
- Semiconductor manufacturing equipment
Installation note:
Apply thread sealant (PTFE tape or liquid) to port threads before assembly.
Tighten M5 mounting screws diagonally to 0.8-1.2 N·m torque.
Perform pressure test at 1.5x operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | 6V0500M7F |
