Airtac 6V-F Base 6V0500M8F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V0500M8F Technical Specifications
- Model: 6V0500M8F
- Type: Standard cylinder mounting base (Fixed type)
- Material: Aluminum alloy ADC12
- Mounting hole specification: M8×1.25 threaded
- Surface treatment: Anodized (Natural silver)
- Operating temperature: -20℃ to 80℃
- Max lateral load capacity: 450N
- Axial load capacity: 600N
- Weight: 0.52kg ±2%
- Dimensions: 50mm(L) × 50mm(W) × 20mm(H)
- Compatible cylinder series: SC/SU/SI 32-100mm bore sizes
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Corrosion resistance: 96hr salt spray test passed
Precision-machined mounting base featuring anti-loosening thread design with integrated shock-absorbing pads. The diamond-knurled surface enhances grip during installation while maintaining positional accuracy within ±0.2mm. Includes stainless steel reinforcement plates at stress concentration points.
- Robotic arm joint fixation in automotive assembly lines
- Vertical cylinder mounting for packaging machine stoppers
- Multi-axis positioning systems in semiconductor handling
- Vibration-prone environments like CNC tool changers
- Modular pneumatic systems requiring quick reconfiguration
Installation protocol:
Apply 2.5-3.5N·m torque during M8 screw fastening. Use thread-locking compound
(Loctite 243 recommended) for permanent installations. Clean mounting surface
with isopropyl alcohol prior to assembly.
