Airtac 6V-F Base 6V0500M9F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Base Manifold 6V0500M9F Technical Specifications
- Model: 6V0500M9F (6V-F Series Modular Base)
- Type: 5-station modular base manifold with M9 connector interface
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 850 L/min (ANR)
- Port thread depth: 12.5±1 mm
- Mounting pitch: 18 mm between stations
- Seal material: HNBR (Hydrogenated Nitrile) with glass fiber reinforcement
- Temperature resistance: -20℃ to 120℃ (continuous operation)
- Surface treatment: Black anodized aluminum alloy
- Weight: 320±10g
- Dimensions: 90mm(L) × 36mm(W) × 28mm(H)
- Compatibility: Designed for 6V230/240/250 series solenoid valves
- Leakage rate: ≤3 bubbles/min (ISO 6952 test standard)
High-density modular base with precision-machined flow channels, featuring integrated silencer pockets and auto-drainage design. The staggered port configuration enables space-efficient multi-valve arrangements in complex pneumatic circuits. Includes built-in mounting slots for DIN rail (35mm) or direct panel installation.
- Multi-valve control stations in packaging machinery
- Centralized pneumatic distribution in automotive assembly lines
- Compact valve clusters for semiconductor handling robots
- Modular HVAC control systems
- Mobile equipment requiring vibration-resistant manifolds
Installation guidelines:
Apply 2-3Nm torque during valve mounting. Use only compatible M3×8 mounting screws.
For vertical installations, orient identification label upward. Perform pressure decay test
after assembly - maximum 0.01MPa drop in 30 seconds at 0.6MPa input.
| Property | Property Value |
|---|---|
| sku | 6V0500M9F |
