AirTAC 6V100M-11 6V-F Base (6V100M11F)
$23.95
Regular price
$31.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V100M11F
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enables modular integration of directional control valves from the same series into valve banks, achieving space optimization and cost efficiency;
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
Installation guidelines:
Torque mounting screws to 0.6-0.8 N·m. Apply thread sealant to port connections.
Use M5x0.8 mounting screws (max protrusion 8mm below base). Maintain ambient
humidity below 85% RH to prevent condensation in air channels.
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base 6V100M11F Technical Specifications
- Model: 6V100M11F
- Type: Modular valve manifold base (6V-F series)
- Port configuration: 1/4" NPT (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Flow capacity: 350 NL/min (Cv=0.53)
- Mounting pattern: ISO 15407-1 compliant
- Material: Aluminum alloy (anodized surface treatment)
- Seal type: NBR rubber (optional FKM available)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 220g ±5%
- Dimensions: 100mm(L) × 30mm(W) × 40mm(H)
- Port spacing: 18mm center-to-center
- Surface roughness: Ra ≤3.2μm
- Compatibility: Works with 6V1/6V2 series valves
Precision-machined manifold base for creating multi-valve pneumatic control systems. Features leak-proof design with O-ring seals and standardized mounting holes for modular expansion. Includes integrated air passageways for simplified piping. Rated for 1 million+ cycles.
Common Applications:
- Centralized control systems for packaging machinery
- Robotic end-effector pneumatic clusters
- Automated assembly line valve banks
- CNC machine tool pneumatic circuits
- Semiconductor manufacturing equipment
Installation guidelines:
Torque mounting screws to 0.6-0.8 N·m. Apply thread sealant to port connections.
Use M5x0.8 mounting screws (max protrusion 8mm below base). Maintain ambient
humidity below 85% RH to prevent condensation in air channels.
